Lumberg Minimodul Series Straight Through Hole PCB Header 3 Contacts 2.5 mm Pitch 1 Row Shrouded 2,5 MSF/O 03
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 160V |
| Brand | Lumberg |
| Orientation | Straight |
| Current | 5A |
| Model | 2,5 MSF/O 03 |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyamide |
| Contact Material | Brass |
| Series | Minimodul |
| Termination Type | Solder |
| Maximum Operating Temperature | 120°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2.5mm |
| Contact Plating | Tin |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Shrouded design for enhanced protection and durability.
- Constructed with glass filled polyamide housing material for strength.
- Brass contact material with tin plating ensures excellent conductivity.
- Supports current up to 5A and voltage up to 160V.
- Operates efficiently between -40°C and 120°C temperature range.
- Features through-hole mount type for secure PCB installation.
- Male contact gender with straight orientation for versatile application.
- Suitable for signal and low load currents in electronic components.
Product Description
The Lumberg Minimodul Series Straight Through Hole PCB Header model 2,5 MSF/O 03 is a high-quality, shrouded PCB header designed for robust wire-to-board connections in electronic assemblies. It features 3 male contacts arranged in a single row with a pitch of 2.5 mm, providing reliable signal and power transmission in various electronic devices.
Manufactured with durable glass filled polyamide housing material, the header offers mechanical strength and excellent resistance to environmental factors. The brass contacts, plated with tin, ensure superior electrical conductivity and corrosion resistance, which is critical in maintaining stable connections.
Rated for a maximum current of 5A and voltage of 160V, this PCB header performs reliably within an operational temperature range of -40°C to 120°C, making it suitable for use in diverse industrial and electronic environments.
Its through-hole mounting type and straight orientation aid in secure and straightforward PCB installation, compatible with crimp contact housings from the 3114 Series. The shrouded design enhances connector safety by preventing accidental contacts and improving connector longevity.
This product is ideal for use in electronic components, power and connectors assemblies, signal processing modules, and other applications requiring dependable wire-to-board interfaces with low to medium current loads.
Shrouded to provide protection against environmental influence and mechanical stress. Compatible with crimp contact housings for efficient cable harnessing. Glass filled polyamide housing material offers enhanced durability.
Brass contacts with tin plating for dependable electrical performance. Designed for use in industrial, manufacturing, and electronic equipment assembly. Supports signal and low load current applications up to 5A. Through-hole mount type ensures firm PCB integration.
Operates reliably over wide temperature ranges, -40°C to 120°C.
Whether for prototyping or production runs, the Lumberg Minimodul Series PCB Header 2,5 MSF/O 03 is a dependable choice to meet demanding electronics manufacturing and assembly needs. Explore the full range of PCB Headers categories on EnvMart for comprehensive solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a maximum current of 5A.
It is rated for a maximum voltage of 160V.
The contacts are arranged with a pitch of 2.5 mm.
It operates efficiently within a temperature range of -40°C to 120°C.
This model features a through-hole mount type for secure PCB installation.
The housing is made of glass filled polyamide, while the contacts are brass plated with tin.
It has 3 male contacts arranged in a single row.
The contacts have a straight orientation, which aids in versatile application.
Yes, it is suitable for signal and low load current applications in electronic components.
It uses solder termination type for connections.
The country of origin for this PCB header is India.
This model is part of the Lumberg Minimodul Series.
