Panasonic Shielded Wirewound Surface Mount Inductor, 2 μH ±20% Inductance, 19.4 A Maximum DC Current, Metal Composite ETQP5M
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 5mm |
| Length | 10.9mm |
| Model | ETQP5M |
| Depth | 10mm |
| Packaging | Tape & Reel |
| Series | ETQP5M |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Metal Composite |
| Inductance | 2μH |
| Standards/Approvals | RoHS |
| Package/Case | Surface Mount |
| Maximum DC Current | 19.4A |
| Pin Count | 2 |
| Maximum DC Resistance | 5.06mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Employs a metal composite core for high heat resistance and reliability.
- Wirewound construction ensures excellent inductance stability and performance.
- Shielded design reduces electromagnetic interference effectively.
- Operates reliably up to 150°C including self heating.
- Complies with automotive AEC-Q200 standard for quality assurance.
- Utilizes tape and reel packaging suitable for automated assembly.
- Features low audible noise and high vibration resistance.
- Maximum DC resistance is 5.06 mΩ ensuring efficient current flow.
Product Description
Panasonic ETQP5M is a shielded wirewound Surface Mount Inductor built around a metal composite core, providing high heat resistance and excellent reliability. It is designed to withstand industrial and automotive environments with a maximum operating temperature of 150°C, including self-heating effects.
The inductor delivers an inductance of 2 μH with a tolerance of ±20%, and can handle a maximum DC current of 19.4 A. Its wirewound construction offers outstanding inductance stability through the use of a ferrous alloy magnetic material. The shielded design minimizes electromagnetic interference, making it suitable for sensitive electronics.
The part is compliant with the AEC-Q200 automotive standard, ensuring quality and durability in automotive applications. Its compact physical size, with dimensions of 10.9 mm length, 5 mm height, and 10 mm depth, allows for efficient usage on crowded printed circuit boards.
Additional features include low audible noise, high vibration resistance due to newly developed integral construction, and a maximum DC resistance of 5.06 mΩ to provide efficient current conduction. The inductor is moulded and surface mount terminated, supplied in tape and reel packaging for easy automated placement.
This product is ideal for noise filtering in various drive circuitry requiring operation under high temperatures and peak current handling capability in industrial, automotive, and electronics manufacturing environments.
Employs a metal composite core for durability and heat handling. Wirewound construction ensures inductance stability in demanding conditions. Shielding reduces electromagnetic noise for improved signal integrity. High temperature tolerance up to 150°C including internal heat.
Complies with automotive AEC-Q200 standards for robust quality. Compact dimensions facilitate integration into dense PCB layouts. Low audible noise contributes to silent operation. High vibration resistance supports reliability in harsh settings.
Surface mount termination and tape & reel packaging enable automated assembly. Suitable for industrial, automotive, and electronic circuit noise filtering applications. Explore more industrial electronic components like this Panasonic ETQP5M inductor within EnvMart's Electronics Components catalog.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this model is 2 μH with a tolerance of ±20%.
It can handle a maximum DC current of 19.4 A.
The dimensions are 10.9 mm in length, 5 mm in height, and 10 mm in depth.
The maximum operating temperature is 150°C, including self-heating effects.
It employs a metal composite core, which provides high heat resistance and reliability.
The maximum DC resistance is 5.06 mΩ, ensuring efficient current flow.
It complies with the AEC-Q200 automotive standard and is RoHS approved.
The termination style is surface mount, suitable for automated assembly.
It features a wirewound construction, which ensures excellent inductance stability.
It is supplied in tape and reel packaging, facilitating easy automated placement.
It is suitable for noise filtering in various drive circuitry, particularly in industrial, automotive, and electronics manufacturing environments.
The maximum self-resonant frequency is 100 kHz.
