Murata 24 MHz Crystal Unit ±10 ppm Surface Mount 4-Pin 0.65 mm Height 1.6 mm Length 2 mm Width XRCGB24M000F1SBDR0
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Murata |
| Height | 0.65mm |
| Length | 1.6mm |
| Model | XRCGB24M000F1SBDR0 |
| Packaging | Tape |
| Width | 2mm |
| Mount Type | Surface |
| Series | XRCGB |
| Maximum Operating Temperature | 105°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| Pin Count | 4 |
| Standard Frequency | 24MHz |
| Load Capacitance | 12pF |
| Series Resistance | 70Ω |
Key Features
- Standard frequency of 24 MHz ideal for communication clocks like Wi-Fi and Bluetooth devices.
- Compact dimensions of 1.6 mm length, 2 mm width, and 0.65 mm height minimizes PCB space usage.
- Load capacitance rating of 12 pF supports stable oscillation performance.
- Series resistance of 70 Ω ensures reliable signal quality in applications.
- Operational temperature range from -40°C to +105°C suitable for varied environments.
- Surface mount package supplied on tape for efficient automated PCB assembly.
- Compliant with RoHS directive, lead-free construction promotes environmental safety.
- Manufactured in Japan with Murata’s advanced quartz crystal technology for precision.
Product Description
Murata XRCGB24M000F1SBDR0 24 MHz Crystal Unit provides precise frequency generation with a tolerance of ±10 ppm and a compact surface mount 4-pin form factor measuring 1.6 mm by 2 mm by 0.65 mm. This crystal unit is designed for demanding electronic applications requiring accurate clocks, including PCs, visual equipment, and small portable devices.
The unit features a 24 MHz standard frequency with a 12 pF load capacitance and 70 Ω series resistance for consistent and reliable oscillation performance. It supports a wide operating temperature range from -40°C to 105°C, ensuring stability across industrial and commercial environments. The device is supplied as tape packaging, facilitating automated assembly processes.
Murata's XRCGB series crystal units employ high-grade quartz crystal elements and advanced packaging techniques to achieve small size and excellent frequency accuracy. This makes them suitable for communication clocks such as those in Wi-Fi and Bluetooth modules. Being RoHS compliant and lead-free, the unit meets environmental safety standards.
Manufactured in Japan, this product guarantees high quality and precision required by industrial and consumer electronics sectors. Its small size supports PCB space optimization without sacrificing performance.
Standard frequency: 24 MHz with ±10 ppm tolerance. Compact surface mount 4-pin package reduces footprint. Load capacitance of 12 pF for stable operation. Series resistance is 70 Ω for signal integrity. Wide temperature operation: -40°C to +105°C.
Supplied on tape, ideal for automated PCB assembly. RoHS compliant and lead-free construction. Manufactured in Japan ensuring top quality standards. This crystal unit is ideal for industrial, communication, computer, and portable electronic applications where precise frequency control and small package size are necessary.
Discover more Crystal Units and similar precision components at EnvMart to enhance your electronic designs with reliable frequency control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The standard frequency of this crystal unit is 24 MHz with a tolerance of ±10 ppm.
This model has compact dimensions measuring 1.6 mm in length, 2 mm in width, and 0.65 mm in height.
The load capacitance rating for this crystal unit is 12 pF, which supports stable oscillation performance.
The series resistance of this crystal unit is 70 Ω, ensuring reliable signal quality in applications.
The operational temperature range for this model is from -40°C to +105°C, suitable for varied environments.
It is supplied on tape, which facilitates efficient automated PCB assembly processes.
This unit uses a surface mount package type, which helps to minimize PCB space usage.
This product is manufactured in Japan, ensuring high quality and precision.
It is suitable for communication clocks in devices such as Wi-Fi and Bluetooth modules, as well as other electronic applications requiring accurate clocks.
This model has a pin count of 4, which is typical for surface mount crystal units.
This crystal unit belongs to the XRCGB series, which is known for its advanced quartz crystal technology.
Yes, the crystal unit is RoHS compliant and features lead-free construction, promoting environmental safety.
