XP Power HRL30 DC/DC Converter, 1500V DC Output, 24V DC Input, 20mA Output Current, 30W Power, Through Hole Mount HRL30
Specifications
| Country of Origin | Vietnam |
|---|---|
| Voltage | Converters / DC-DC Converters XP Power HRL30 DC/DC Converter, 1500V dc/, 24V dc |
| Brand | XP Power |
| Efficiency | 0.85% |
| Operating Temperature | -40°C to +70°C |
| Length | 76.2mm |
| Model | HRL30 |
| Gross Weight | 120g |
| Width | 50.8mm |
| Mount Type | Through Hole |
| Series | HRL30 |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -40°C |
| MTBF | 1mH |
| Number of outputs | 1 |
| Ripple and Noise | 0.05% |
| Maximum Output Power | 30W |
| Maximum Input Voltage | 24V dc |
| Standards/Approvals | 60950, EN 62368, UL IEC, CSA, UL |
| Number of Pins | 14 |
| Output Voltage 1 | 1500V dc |
| Output Current 1 | 20mA |
Key Features
- This product features a through hole mounting type for easy PCB integration.
- It offers a 20mA output current to support low power electronic circuits.
- Designed to operate efficiently with a low ripple noise of 0.05% ensuring stable voltage output.
- Operating temperature range from -40°C to 70°C for reliable performance in varied environments.
- Includes protections for short circuit, arc, and overload enhancing device safety.
- Constructed with a compact form factor, measuring 76.2mm in length and 50.8mm in width.
- Complies with international standards such as 60950, EN 62368, UL IEC, and CSA for quality assurance.
- High efficiency operation with over 80% efficiency and low electromagnetic interference.
Product Description
XP Power HRL30 DC/DC Converter Model HRL30 is a miniature, regulated high voltage converter designed for electronic component applications requiring stable and accurate voltage control. It supports an output voltage of 1500V DC from a 24V DC input, delivering up to 30W power with 20mA output current, suitable for sensitive and precision electronics.
The converter employs a proprietary design allowing for constant voltage and current operation with automatic crossover to current limiting mode, preventing overloads. Its through hole mount type provides robust PCB integration, ensuring durability in various industrial and laboratory environments.
This device is designed for operation over a wide temperature range from -40°C to +70°C, making it suitable for harsh conditions often encountered in industrial, manufacturing, and scientific instrumentation applications.
Protection features including short circuit, arc, and overload safeguards contribute to reliable and safe operation. The low ripple noise (0.05%) and high efficiency above 80% minimize electrical interference and power loss, enhancing overall system performance.
With 14 pins and weighing approximately 120g, the HRL30 series conforms to international safety and quality standards including 60950, EN 62368, UL IEC, CSA, and UL approvals. This makes it an ideal component for use in industrial equipment, HVAC systems, medical devices, and high voltage laboratory setups.
This converter delivers regulated output voltage and current with programmable settings for application-specific requirements. It includes on-board +5V reference voltage for easy interfacing with other electronics. Built with digital compatible voltage and current monitors to facilitate automated control and monitoring systems.
The HRL30's miniature design optimizes space utilization in electronic assemblies. Manufactured in Vietnam under strict quality controls, ensuring product reliability and durability.
This XP Power HRL30 DC/DC Converter can be browsed in the EnvMart Electronics & Electricals category for DC/DC Converters, ideal for those seeking high voltage, precise power conversion modules.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The HRL30 DC/DC Converter provides an output voltage of 1500V DC.
It requires a 24V DC input voltage to operate effectively.
The maximum output power of this converter is 30W.
This model delivers an output current of 20mA.
The dimensions are 76.2mm in length and 50.8mm in width.
It operates within a temperature range of -40°C to +70°C.
This converter features a through hole mounting type for easy PCB integration.
The ripple and noise level is specified at 0.05%.
It complies with international standards including 60950, EN 62368, UL IEC, and CSA.
This model has a total of 14 pins.
The efficiency of the HRL30 is rated at over 80%.
It includes protections for short circuit, arc, and overload to enhance safety.
