ROHM Schottky Barrier Diode 30 V 200 mA Surface Mount SOT-23 Package BAT54SHYFHT116
Specifications
| Country of Origin | India |
|---|---|
| Brand | ROHM |
| Height | 1.15mm |
| Length | 3.1mm |
| Model | BAT54SHYFHT116 |
| Width | 1.5mm |
| Mount Type | Surface |
| Series | BAT54SHYFH |
| Package Type | SOT-23 |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 200mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 2μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 600mA |
| Maximum Forward Voltage Vf | 0.8V |
| Peak Reverse Recovery Time trr | 50ns |
Key Features
- The diode features a low forward voltage drop for high efficiency performance.
- Compact SOT-23 package ideal for space-sensitive electronic circuits.
- Maximum continuous forward current of 200 mA supports small current rectification.
- Peak reverse repetitive voltage is rated at 30 volts.
- Highly reliable semiconductor compliant with RoHS and automotive AEC-Q101 standards.
- Fast recovery time of 50 nanoseconds ensures efficient switching.
- Peak non-repetitive forward surge current of 600 mA supports transient surges.
- Extremely low peak reverse current of 2 microamperes reduces leakage losses.
Product Description
The ROHM BAT54SHYFHT116 is a high-reliability Schottky Barrier Diode optimized for automotive and industrial applications requiring low forward voltage and compact packaging. Featuring a SOT-23 surface mount package, it provides an efficient rectification solution with a maximum continuous forward current of 200 mA and peak reverse voltage of 30 V.
This diode exhibits a maximum forward voltage of 0.8 V and an ultra-fast peak reverse recovery time of 50 nanoseconds, enabling swift switching in sensitive electronics. Its peak non-repetitive forward surge current rating of 600 mA accommodates transient spikes, while the extremely low peak reverse current of 2 microamperes minimizes leakage, enhancing overall circuit efficiency.
Measuring just 3.1 mm in length, 1.5 mm in width, and 1.15 mm in height, the compact SOT-23 package supports high-density PCB layouts. The product complies with RoHS directives and meets the automotive AEC-Q101 standards, making it suitable for demanding automotive electronics and other industrial environments where reliability is critical.
Low forward voltage enhances energy efficiency in rectification. Compact surface mount format saves PCB space. High peak reverse voltage of 30 V supports robust protection. Fast recovery time allows operation in high-frequency circuits.
Automotive-grade qualification ensures dependable performance.
This Schottky Diode is ideal for industrial manufacturing, automotive electronics, power management circuits, and other applications requiring fast, low-loss diode performance. Explore the complete range of semiconductor components at EnvMart for all your design requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this diode is 200 mA.
The peak reverse repetitive voltage rating is 30 V.
The dimensions of the SOT-23 package are 3.1 mm in length, 1.5 mm in width, and 1.15 mm in height.
The peak non-repetitive forward surge current is rated at 600 mA.
The maximum forward voltage drop is 0.8 V.
The peak reverse recovery time is 50 nanoseconds.
The peak reverse current is extremely low at 2 microamperes.
Yes, it complies with RoHS directives and meets the automotive AEC-Q101 standards.
This diode features a surface mount type.
This Schottky diode is suitable for automotive electronics, power management circuits, and other applications requiring fast, low-loss performance.
This model has a pin count of 3.
The country of origin for this diode is India.
