TE Connectivity HPI Series Vertical Surface PCB Header, 2 Contacts, 2 mm Pitch, 1 Row, Shrouded 1775470-2
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | TE Connectivity |
| Orientation | Vertical |
| Current | 3A |
| Mount Type | Surface |
| Housing Material | Polyamide 9T Fibreglass |
| Contact Material | Brass |
| Series | HPI |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Standards/Approvals | UL 94 V-0 |
| Contact Plating | Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2mm |
Key Features
- The connector features a shrouded design for improved durability.
- It supports a current rating of 3 A for reliable power transmission.
- Constructed with a polyamide 9T fiberglass housing for high temperature stability.
- Equipped with brass contacts plated with tin for excellent conductivity.
- Designed for vertical orientation with one row of contacts.
- Termination is surface mount with a 2 mm tail pin length for PCB compatibility.
- Operating temperature ranges from -25°C to 85°C for versatile use.
- Meets UL 94 V-0 flammability standard ensuring safety compliance.
Product Description
TE Connectivity 1775470-2 is a high-quality PCB header from the HPI series, designed for vertical surface mounting with 2 contact positions and a 2 mm pitch. This shrouded connector offers a robust wire-to-board interface ideal for electronics manufacturing and repair.
Its polyamide 9T fiberglass housing provides enhanced thermal resistance, making it suitable for operating temperatures from -25°C up to 85°C. The connector utilizes brass contact material with tin plating to ensure low resistance and stable connectivity under varying conditions.
This PCB header features a single row with a pitch of 2 mm, tailored for surface mount technology on printed circuit boards. The termination type is surface mount with a tail pin length of 2 mm, facilitating precise and reliable soldering.
Rated for 3 A current and 250 V voltage, it supports a broad range of industrial and commercial electronics applications. The shrouded design offers protection and alignment support during board assembly.
The connector supports a wire-to-board system, emphasizing secure electrical connections. The housing material enhances mechanical strength and resistance to environmental stress. The product complies with UL 94 V-0 standards, providing flame retardant safety.
The vertical orientation and single row configuration optimize PCB space utilization. Designed for surface mount installation, compatible with standard PCB assembly processes.
TE Connectivity 1775470-2 PCB Headers are widely used in electronic and electrical components manufacturing, instrumentation, telecommunications, and control systems. Their reliability and compact design make them suitable for high-performance industrial and laboratory applications.
Explore more quality TE Connectivity PCB connectors and headers in the Electronics Components category on EnvMart for your industrial and commercial requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 3 A, ensuring reliable power transmission.
The voltage rating for this PCB header is 250 V, making it suitable for various electronic applications.
It features a single row configuration with a pitch of 2 mm and includes 2 contacts.
The housing is made of polyamide 9T fiberglass, while the contacts are brass plated with tin for excellent conductivity.
It operates within a temperature range of -25°C to 85°C, allowing versatile use in various environments.
This unit features a surface mount termination type with a tail pin length of 2 mm for compatibility with PCBs.
It meets the UL 94 V-0 flammability standard, ensuring safety compliance in its applications.
It employs a wire-to-board connector system, emphasizing secure electrical connections.
The shrouded design enhances durability and provides protection and alignment support during board assembly.
The country of origin for this product is India.
It is widely used in electronics manufacturing, telecommunications, instrumentation, and control systems.
This model is designed for vertical orientation, optimizing PCB space utilization.
