Recom Switching Power Supply 5V DC 10W 80-305V AC Input PCB Mount RAC10-05SC/277

Free Delivery in India | Lowest Global Shipping Charges

Recom Switching Power Supply 5V DC 10W 80-305V AC Input PCB Mount RAC10-05SC/277

Name: Recom Switching Power Supply 5V DC 10W 80-305V AC Input PCB Mount RAC10-05SC/277
Brand: Recom
SKU: 105732
Price: 20.22 USD
Availability: InStock



Category Switching Power Supplies Brand Recom Condition New

Specifications

Country of Origin	Taiwan
Brand	Recom
Power	10W
Efficiency	78%
Length	52.4mm
Model	RAC10-05SC/277
Depth	23.5mm
Gross Weight	62g
Width	27.4mm
Mount Type	PCB
Series	RAC10-C/277
Maximum Operating Temperature	75°C
Minimum Operating Temperature	-20°C
Number of outputs	1
Maximum Input Voltage	305V ac
Maximum Output Voltage	5V dc
SMPS Output Current	2A
Minimum Input Voltage	80V ac

Key Features

Compact PCB mount design with dimensions of 52.4 x 27.4 x 23.5 mm.
Output current of 2A suitable for low power electronic equipment.
Wide operating temperature range from -20°C to 75°C for harsh environments.
High efficiency of 78% reduces heat dissipation during use.
Robust epoxy case with fiberglass ensures resistance to heat and mechanical wear.
Includes continuous short-circuit protection for increased reliability.
Low ripple and noise level of 50 mVp-p to minimise electrical interference.
Certified to multiple international standards including UL 60950-1 and RoHS compliant.

Product Description

Recom RAC10-05SC/277 Switching Power Supply is a highly reliable PCB mount unit designed to convert a wide AC input voltage range of 80 to 305V to a steady 5V DC output at 10W power. It features a single output delivering 2 amps for low power electronic devices.

The robust epoxy housing with fiberglass reinforcement offers excellent protection against heat, wear, and environmental factors. With its compact footprint of 52.4 mm length, 27.4 mm width, and 23.5 mm thickness, it integrates seamlessly into dense electronic assemblies.

Operating reliably from -20°C up to 75°C, this power supply suits demanding industrial, medical, and telecommunication applications. Its efficiency rating of 78% helps reduce energy loss and excessive heat generation, promoting long service life with a mean time between failures of approximately 320,000 hours at 25°C.

Advanced continuous short-circuit protection and low ripple noise of 50 mVp-p minimize system disturbances and enhance operational safety. The product complies with stringent international standards including CAN/CSA C22.2 No. 60950-1-07, EN 55022 Class B, EN 60950-1, UL 60950-1, IEC 60950-1, and RoHS directives, confirming its industrial-grade certification.

Weighing only 62 grams, the RAC10-05SC/277 reduces mechanical stress on mounting points and is easy to handle during installation. It is ideally suited for telecommunication systems, medical instrumentation, and industrial automation environments requiring dependable DC power conversion.

Compact and lightweight PCB Mount switching power supply with 5V DC output. Wide input voltage range of 80 to 305V AC supports global power sources. Continuous short-circuit protection enhances device longevity and safety.

Low noise and ripple output minimize interference with sensitive electronics. Conforms to multiple international safety and electromagnetic compatibility standards. Epoxy fiberglass case for heat resistance and mechanical durability.

High efficiency ensures reduced energy waste and cooler operation. Suitable for industrial automation, telecommunications, and medical devices. Operating temperature range from -20°C to 75°C suits harsh working conditions.
