Wurth Elektronik 5-Channel Adjustable DC/DC Power Supply Module 24V 3A PFM 7-Pin 171032401
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | Wurth Elektronik |
| Height | 4.57mm |
| Length | 10.16mm |
| Width | 9.85mm |
| Mount Type | Surface |
| Output type | Adjustable |
| Series | MagI3C |
| Topology | Step Down |
| Maximum Operating Temperature | 125°C |
| Package Type | PFM |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 5 |
| Maximum Input Voltage | 42V |
| Protection | Thermal shut-down, inrush current, overvoltage and under-voltage |
| Maximum Switching Frequency | 0.8MHz |
| Maximum Output Current | 3A |
| Maximum Output Voltage | 24V |
| Minimum Input Voltage | 6V |
| Pin Count | 7 |
| Minimum Output Voltage | 5V |
| 7 PIN PFM (TO-263) | (L) 9.85 mm, (W) 10.16 mm, (H) 4.57 mm |
Key Features
- Operates with input voltage from 6V to a maximum of 42V.
- Delivers a maximum output current of 3A suitable for multiple applications.
- Features step-down topology with five outputs for flexible power distribution.
- Employs PFM package type with 7-pin surface mount configuration.
- Built-in protection includes thermal shutdown, inrush current limitation, overvoltage and undervoltage safeguards.
- Compact dimensions with length 10.16mm, width 9.85mm, and height 4.57mm.
- Maximum switching frequency of 0.8 MHz enables efficient power conversion.
- Operating temperature range from -40°C up to 125°C for harsh environments.
Product Description
Wurth Elektronik 171032401 is a 5-Channel DC/DC Power Supply Module offering adjustable output voltage between 5V and 24V with a maximum output current of 3A. This module features a step-down (buck) topology and is packaged in a compact PFM 7-pin surface mount (TO-263) package.
Designed for robustness and reliability, it supports wide input voltage ranging from 6V to 42V, making it suitable for various industrial and electronic power management applications.
The module integrates soft-start capability ensuring safe power-up and includes comprehensive protective measures such as thermal shutdown, inrush current limiting, overvoltage and undervoltage protection. Its switching frequency peaks at 0.8 MHz, contributing to high efficiency and low electromagnetic interference (EMI), compliant with EN55022 class B standards.
With compact size dimensions of 10.16 mm length, 9.85 mm width, and 4.57 mm height, this device efficiently fits into space-constrained designs. The operating temperature range of -40°C to 125°C extends its usage to harsh environments and critical industrial scenarios.
The Wurth Elektronik MagI³C series power modules are optimized for point of load DC-DC conversions, industrial controls, telecommunications, and embedded processing units including MCU, MPU, DSP, and FPGA systems. Its low noise operation and under voltage lockout protection ensure stable performance across applications.
Operates with input voltage from 6V to 42V. Maximum output current rated at 3A with adjustable output voltage up to 24V. Contains onboard protection for thermal shutdown, overvoltage, undervoltage, and inrush current. Compact surface mount PFM TO-263 package with 7 pins.
Wide operating temperature range of -40°C to 125°C for industrial use. Switching frequency up to 0.8 MHz delivering high efficiency up to 97%. Compliant with EN55022 class B EMI standards for low noise. Suitable for industrial control, telecom, and embedded processor power supply.
Safe power-up feature with soft-start functionality. Manufactured in Malaysia maintaining high-quality standards. Explore the Wurth Elektronik category on EnvMart for advanced power management modules tailored for demanding industrial and commercial projects.
Explore more products in our Power Management ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output current of the module is 3A.
It operates with an input voltage ranging from 6V to a maximum of 42V.
The output voltage can be adjusted between 5V and 24V.
This model features five outputs for flexible power distribution.
The dimensions are 10.16 mm in length, 9.85 mm in width, and 4.57 mm in height.
It is packaged in a PFM 7-pin surface mount configuration (TO-263).
The maximum switching frequency is 0.8 MHz.
The operating temperature range is from -40°C to 125°C.
It is suitable for industrial controls, telecommunications, and embedded processing units.
It is manufactured in Malaysia.
