Molex C-Grid III Series Vertical Through Hole PCB Header 6 Contacts 2.54 mm Pitch Shrouded 901361106

Molex 901361106 is a reliable high-quality PCB header from the C-Grid III Series designed for vertical through-hole mounting on printed circuit boards. It features 6 male brass contacts with tin plating, arranged in a single row and spaced at a precise 2.54 mm pitch. The housing is made from durable polyester, providing excellent electrical insulation and mechanical protection for the contacts.

This shrouded connector system is optimized for wire-to-board applications and supports a maximum current of 3 amps and voltage rating of 350 V, making it suitable for a range of electronic and industrial equipment. The termination type is solder, providing a secure and stable connection on PCB assemblies.

The component is built to withstand operating temperatures from -55°C up to 125°C, making it versatile for demanding environments including industrial automation, manufacturing electronics, instrumentation, and HVAC controls.

Dimensions such as tail pin length (2.9 mm) and mating pin length (6.75 mm) ensure proper mechanical fit and electrical contact integrity during mating with corresponding connectors.

Manufactured in Malaysia under strict quality standards, this Molex vertical PCB header ensures performance consistency in demanding technical settings. This PCB header supports a current rating of 3 amps for reliable electrical performance.

Constructed with brass contacts plated in tin, ensuring corrosion resistance and durability. The housing is made of polyester material, providing insulation and mechanical strength. It features a single row orientation with vertical body and shrouded connector system.

Designed for through-hole mounting with solder termination type for robust connection. Operating temperature range from -55°C to 125°C suitable for various industrial applications. Tail pin length of 2.9 mm and mating pin length of 6.75 mm ensure secure mechanical and electrical contact.

Voltage rating is up to 350 V, ideal for electronic component assemblies. Manufactured in Malaysia maintaining quality and consistency.

Ideal for industrial, manufacturing, laboratory, and commercial electronics equipment assembly, this Molex PCB header in C-Grid III Series offers precision, durability and connectivity assurance. Browse EnvMart's extensive catalog for compatible PCB connectors and accessories to complete your system integration projects.
