STMicroelectronics Through Hole 3-Pin TRIAC 600 V Gate Trigger 1.3 V BTB12-600CWRG

STMicroelectronics BTB12-600CWRG is a high-performance TRIAC designed for controlling AC power in industrial, commercial, and consumer electronics applications. This device is packaged in a through hole TO-220 3-pin configuration, providing easy assembly and reliable thermal performance. Rated for a repetitive peak reverse voltage of 600 volts and a rated average on-state current of 12 amperes, it suits switching and phase control tasks.

The TRIAC features a low gate trigger voltage of 1.3 V and a maximum gate trigger current of 35 mA, enabling precise activation at low power input. Its maximum operating temperature of 125°C and minimum operating temperature of -40°C ensure robustness in harsh environments. With a surge current rating of 126 A, the device accommodates transient current spikes during startup or fault conditions without damage.

Peak on-state voltage of 1.55 V contributes to minimized power loss during conduction, improving efficiency. The repetitive peak off-state current is maintained at 1 mA, ensuring stable non-conduction states. This TRIAC does not carry automotive certifications and is intended for standard industrial applications.

Its compact size with a height of 15.9 mm and length of 10.4 mm fits into a wide variety of circuit layouts. Manufactured in China, this component complies with quality and reliability norms customary in semiconductor discrete components used in power electronics.

This TRIAC supports a rated average on-state current of 12 amperes. It is housed in a robust TO-220 through hole mount package suitable for power applications. The device features a maximum repetitive peak reverse voltage of 600 volts.

It has a maximum gate trigger current of 35 milliamperes for reliable switching. The TRIAC operates within a temperature range from -40°C to 125°C. Surge current rating reaches up to 126 amperes for transient conditions.

The device delivers a maximum gate trigger voltage of 1.3 volts and holding current of 35 milliamperes. Peak on-state voltage is rated at 1.55 volts, ensuring efficient conduction. Repetitive peak off-state current is limited to 1 milliampere to maintain performance.

Manufactured in China under strict quality standards for industrial and commercial use.

Ideal for industrial power control, lighting regulation, motor speed control, and heating systems, the STMicroelectronics BTB12-600CWRG TRIAC is a reliable component for engineers seeking precise and durable semiconductor solutions. Explore other semiconductor offerings from STMicroelectronics and related power devices in the EnvMart catalog for comprehensive electronics design needs.
