Wurth Elektronik WE-MAPI 3020 Shielded Wirewound Surface Mount Inductor with Magnetic Iron Alloy Core 1.2μH ±20% 74438336012
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | Wurth Elektronik |
| Height | 2mm |
| Length | 3mm |
| Depth | 3mm |
| Packaging | Tape & Reel |
| Series | WE-MAPI |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Core Material | Magnetic Iron Alloy |
| Inductance | 1.2μH |
| Standards/Approvals | RoHS, REACH, JEDEC JS709B, IEC 61249-2-21 |
| Package/Case | 3020 |
| Maximum DC Current | 3.9A |
| Maximum DC Resistance | 36mΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 57MHz |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Compact 3020 package size with dimensions 3mm length, 2mm height, and 3mm depth.
- Magnetically shielded construction minimizes acoustic and leakage flux noise.
- Operating temperature range from -40°C to 125°C suitable for automotive use.
- RoHS and REACH compliant with AEC-Q200 automotive certification.
- Maximum DC resistance of 36mΩ ensures efficient power handling.
- Maximum self-resonant frequency of 57MHz for stable filtering performance.
- Surface mount termination style for easy PCB integration.
- Wirewound inductor construction with moulded design enhances durability.
Product Description
Wurth Elektronik 74438336012 WE-MAPI shielded wirewound surface mount inductor provides a reliable magnetic iron alloy core design delivering 1.2μH inductance with ±20% tolerance, suited for demanding electronic applications. The compact 3020 package size and magnetically shielded construction reduce acoustic noise and flux leakage, enhancing device performance and longevity.
The inductor supports a maximum DC current of 3.9A and operates efficiently within a temperature range of -40°C to 125°C, meeting the stringent automotive AEC-Q200 standard. Its maximum DC resistance of 36mΩ ensures low power loss and improved current handling capability.
Certified to RoHS, REACH, JEDEC JS709B, and IEC 61249-2-21 standards, this wirewound and moulded component is suitable for various industrial and commercial uses such as DC/DC converters, FPGA power supply regulation, POL converters, and portable electronic devices including PDAs, digital cameras, smartphones, and tablet PCs.
Surface mount termination style facilitates automated assembly and integration into high-density PCB layouts, enhancing manufacturing efficiency. The WE-MAPI series inductors excel in compact power supply designs requiring low acoustic noise and robust transient current spike handling.
Compact 3020 package with 3mm length, 2mm height, and 3mm depth dimensions. Magnetic iron alloy core for high current rating and low noise. Operational temperature from -40°C up to 125°C suits automotive and industrial environments.
Automotive standard AEC-Q200 compliance. Tape and reel packaging for efficient production handling. Inductance tolerance of ±20% for consistent performance. Low DC resistance of 36mΩ minimizes power losses. Wirewound and moulded construction improves durability and stability.
Ideal for power supplies in mobile and communication devices. Explore more quality surface mount Inductors and passive components at EnvMart for diverse industrial and electronic design solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 1.2μH with a tolerance of ±20%.
The inductor is housed in a compact 3020 package with dimensions of 3mm length, 2mm height, and 3mm depth.
It supports a maximum DC current of 3.9A, ensuring efficient power handling.
The operating temperature range is from -40°C to 125°C, making it suitable for automotive applications.
It features a wirewound construction with a moulded design, enhancing its durability and stability.
The maximum DC resistance is 36mΩ, which helps minimize power losses.
It is certified to RoHS, REACH, JEDEC JS709B, and IEC 61249-2-21 standards, along with AEC-Q200 automotive certification.
The maximum self-resonant frequency is 57MHz, which contributes to stable filtering performance.
This unit features a surface mount termination style, facilitating easy integration into PCBs.
It is packaged in tape and reel format, which is efficient for production handling.
It is suitable for various applications including DC/DC converters, FPGA power supply regulation, and portable electronic devices.
The country of origin for this inductor is Korea.
