Samtec TFM Series Right Angle Through Hole PCB Header 70 Contact 1.27 mm Pitch 2 Row Shrouded TFM-135-02-S-D-LC
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 3.2A |
| Model | TFM-135-02-S-D-LC |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TFM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 70 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Board-to-Board |
Key Features
- Features a shrouded design to protect contacts and ensure secure connections.
- Made with phosphor bronze contacts plated in gold for durability and excellent conductivity.
- Liquid Crystal Polymer housing provides high temperature resistance and mechanical strength.
- Supports a current rating of 3.2 A with a voltage rating of 250 V.
- Suitable for board-to-board connector system with right angle orientation and through hole mount type.
- Operating temperature range from -55°C to 125°C ensures performance in harsh environments.
- Termination type is solder, with male contact gender.
- Row pitch and pitch mating both 1.27 mm (0.050 inch) for precise alignment.
Product Description
Samtec TFM-135-02-S-D-LC is a Right Angle Through Hole PCB Header designed with 70 contacts arranged in 2 rows at a 1.27 mm pitch. This connector is engineered for high performance and reliability in electronic circuit assemblies, providing robust mechanical and electrical connections.
The shrouded housing made of Liquid Crystal Polymer (LCP) enhances the durability and maintains contact alignment, crucial for board-to-board applications. The male pins, constructed of phosphor bronze and plated with gold, ensure excellent conductivity and resistance to corrosion.
This PCB header supports a rated current of 3.2 amperes and a voltage rating of 250 volts, making it suitable for a wide range of electronic applications that require stable electrical performance.
With an operating temperature range from -55°C to 125°C, it is well suited for harsh environments and industrial conditions. The right angle orientation and through hole mount type allow for flexible PCB design integration.
The termination type is solder, providing secure mechanical and electrical integration with the PCB. This component is ideal for electronics manufacturing in sectors such as industrial machinery, automation, laboratory instrumentation, and commercial electronics.
Shrouded 2-row, 70-position male PCB header. 1.27 mm pitch ensuring compact design with precise contact spacing. Phosphor bronze gold-plated contacts for reliable conductivity. Liquid Crystal Polymer housing for thermal and mechanical stability.
Right angle orientation for flexible PCB layout. Rated for 3.2 A current and 250 V voltage. Operating temperature range from -55°C to 125°C. Through hole mount and solder termination for durable PCB attachment. Designed for board-to-board connector systems.
Widely used in industrial, commercial, and laboratory electronic equipment. Explore our comprehensive range of PCB Headers and connectors to meet your precise electronic design requirements here at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 3.2 A.
The voltage rating for this connector is 250 V.
It features phosphor bronze contacts plated in gold and a housing made of Liquid Crystal Polymer.
The TFM-135-02-S-D-LC has a pitch of 1.27 mm and contains 70 contacts arranged in 2 rows.
The operating temperature range is from -55°C to 125°C.
It uses solder termination for secure mechanical and electrical integration with the PCB.
This connector features a right angle orientation, suitable for flexible PCB layout.
This model is designed for through hole mounting.
The contacts in this connector are male.
It is suitable for board-to-board connector systems and widely used in industrial, commercial, and laboratory electronic equipment.
The shrouded design protects the contacts and ensures secure connections, enhancing reliability in electronic circuit assemblies.
The pitch is 1.27 mm (0.050 inch), allowing for precise alignment in compact designs.
