Samtec TSW Series Straight Through Hole Pin Header, 48 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-124-08-G-D

Free Delivery in India | Lowest Global Shipping Charges

Samtec TSW Series Straight Through Hole Pin Header, 48 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-124-08-G-D

Name: Samtec TSW Series Straight Through Hole Pin Header, 48 Contacts, 2.54 mm Pitch, 2 Row, Unshrouded TSW-124-08-G-D
Brand: Samtec
SKU: 108561
Price: 7.96 USD
Availability: InStock



Category PCB Pin Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	550V
Brand	Samtec
Orientation	Straight
Model	TSW-124-08-G-D
Mount Type	Through Hole
Special Features	Many options fo
Housing Material	Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	TSW
Termination	Through-hole
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	48
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board
Contact System	.025" (0.635 mm) square post

Key Features

Constructed with a glass-filled polyester housing for durability.
Phosphor bronze contacts plated with gold ensure reliable conductivity.
Designed for through-hole mounting on PCBs with vertical orientation.
Supports a voltage rating of up to 550V for demanding electronic applications.
Operating temperature range from -55°C to 125°C for versatile industrial use.
Contact system uses 0.025 inch (0.635 mm) square posts for secure connection.
Termination type is solder, suited for permanent assembly.
Unshrouded design facilitates easy access and inspection of contacts.

Product Description

Samtec TSW-124-08-G-D is a high-quality straight through-hole pin header designed for PCB connector applications requiring reliable board-to-board interconnection. This product features 48 male contacts arranged in two rows, each with a 2.54 mm pitch, ideal for precision alignment and stable mechanical connection. The housing is made of tough glass-filled polyester that offers excellent insulation and mechanical robustness.

The phosphor bronze contacts are plated with gold to provide superior conductivity and corrosion resistance, ensuring signal integrity over prolonged use in industrial, electronic manufacturing, and assembly operations. The connector supports a voltage rating up to 550V, accommodating a wide range of power and signal requirements.

Operating reliably in harsh temperature environments from -55°C to 125°C, this pin header is built to meet diverse industrial standards though it carries no specific external certifications. Its through-hole mounting and solder termination provide solid mechanical stability suitable for permanent PCB assembly. With an unshrouded, straight vertical orientation, the connector affords easy access during installation and maintenance.

This pin header is suitable for electronics manufacturing, industrial equipment assembly, and prototyping applications where durable and precise PCB connectors are critical. The 48-contact count supports high pin density requirements in compact electronic devices.

Constructed with glass-filled polyester housing for strength and insulation. Gold-plated phosphor bronze contacts guarantee stable and long-lasting connections. Supports up to 550V for robust electrical performance. Wide operating temperature range of -55°C to 125°C for industrial environments.

Straight, unshrouded through-hole mounting facilitates use in board-to-board systems. Explore more PCB connector solutions and pin header options available at EnvMart to find the ideal components for your electronic design and assembly needs.

Explore more products in our PCB Pin Header category.
