Samtec TSW Series Straight Through Hole Pin Header 20 Contacts 2.54 mm Pitch 2 Row Unshrouded TSW-110-08-T-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-110-08-T-D |
| Mount Type | Through Hole |
| Special Features | Many options fo |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- The header features glass filled polyester housing for durability.
- Contacts are made of phosphor bronze with gold plating for reliable conductivity.
- Designed for board-to-board connector system with straight orientation.
- Supports a wide operating temperature range from -55°C to 125°C.
- Termination type is solder with male contact gender.
- The pitch and row pitch are both 2.54 mm, suitable for standard PCB layouts.
- The pin header uses a .025" (0.635 mm) square post contact system.
Product Description
Samtec TSW-110-08-T-D is a high-quality PCB Pin Header designed for through-hole mounting applications. It features 20 contacts arranged in 2 rows with a pitch of 2.54 mm, suitable for board-to-board connections in electronic assemblies.
The connector housing is constructed of glass filled polyester ensuring mechanical strength and durability. Contacts are manufactured from phosphor bronze and plated with gold to provide excellent electrical conductivity and resistance to corrosion.
This pin header is unshrouded and provides a straight orientation making it easy to solder onto printed circuit boards for reliable and secure connections.
Operating temperature range from -55°C to 125°C allows this header to perform under diverse industrial and commercial environments. The contact system consists of a .025" (0.635 mm) square post that fits standard PCB footprints and designs.
With a voltage rating of 550V, this header can withstand substantial electrical loads in various applications including industrial electronics, telecommunications, instrumentation, and more.
Glass filled polyester housing provides mechanical durability. Phosphor bronze contacts with gold plating ensure conductivity and corrosion resistance. Straight orientation and through-hole mount type for easy PCB assembly.
Operating temperature from -55°C up to 125°C. Two-row, 20 position layout with 2.54 mm pitch. Compatible with board-to-board connector systems. Voltage rating of 550V suitable for various electronic applications. Male contact gender with solder termination type.
This pin header is widely used in industrial machinery, control panels, instrumentation, and other electronic equipment requiring dependable PCB interconnections. Its robust materials and precise construction meet demanding quality standards.
Explore the extensive Samtec PCB connectors range on EnvMart for additional compatible components and accessories.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this pin header is 550V, making it suitable for various electronic applications.
The pitch of the contacts is 2.54 mm, which is standard for many PCB layouts.
This model features 20 contacts arranged in 2 rows.
The housing is made of glass filled polyester, and the contacts are made of phosphor bronze with gold plating for conductivity.
The operating temperature range is from -55°C to 125°C, allowing it to function in diverse environments.
This pin header uses a solder termination type, which is suitable for through-hole mounting.
This model is unshrouded, providing a straight orientation for easy soldering onto PCBs.
The contact system consists of a .025" (0.635 mm) square post, fitting standard PCB footprints.
The contacts are male, which is typical for board-to-board connector systems.
It is widely used in industrial machinery, control panels, instrumentation, and other electronic equipment requiring PCB interconnections.
The country of origin for this pin header is India.
This pin header belongs to the TSW series, which includes various options for PCB connectors.
