Samtec PCB Socket 24-Contact 2 Row 2.54 mm Pitch Straight Through Hole Solder Liquid Crystal Polymer Housing SSW-112-01-L-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.7A |
| Model | SSW-112-01-L-D |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | SSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 24 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Row Pitch | 2.5mm |
Key Features
- The socket features a liquid crystal polymer housing ensuring durability and stability.
- It has a current rating of 4.7 A per pin suitable for various low to medium power electronic applications.
- Contacts are made of phosphor bronze with gold plating for reliable connectivity and corrosion resistance.
- Mount type is through-hole with straight orientation for ease of PCB installation.
- The connector supports voltage ratings up to 655 V withstanding harsh operating conditions.
- Operating temperature ranges from -55°C to 125°C allowing use in demanding environments.
- Row pitch is 2.5 mm in this 2-row design providing compact footprint and spacing.
- Termination type is solder tail optimized for PCB soldering processes.
Product Description
The Samtec SSW-112-01-L-D PCB Socket is a high-quality 24-contact, 2-row straight through-hole socket designed to provide reliable board-to-board electrical connections. Featuring a 2.54 mm pitch and constructed with liquid crystal polymer housing, this socket delivers excellent mechanical strength and resistance to high temperatures.
Its phosphor bronze contacts with gold plating ensure consistent conductivity, corrosion resistance, and low insertion force. Rated to carry 4.7 amperes per pin, the socket supports voltages up to 655 volts, making it appropriate for a wide range of industrial, electronic, and laboratory applications.
The through-hole mounting style and solder tail termination provide secure mechanical and electrical connections to PCBs, while the straight orientation and 2.5 mm row pitch offer a compact yet accessible form factor. The female contact gender socket strip is well suited for various board stacking and connecting solutions.
Operating reliably in temperatures ranging from -55°C to 125°C, the Samtec SSW series sockets are engineered for durability in harsh environmental conditions, including industrial and commercial electronics manufacturing.
The socket's liquid crystal polymer housing provides chemical resistance and stability under thermal stress. Phosphor bronze contacts plated with gold enhance signal integrity and reliability. High current and voltage ratings support diverse electronic component configurations.
Through-hole solder termination ensures robust PCB assembly and repairability. Compact 2 row, 24 contact design with 2.5 mm row pitch optimizes space on circuit boards. Wide operating temperature range enables usage in industrial and harsh environments.
Designed for board-to-board connector systems requiring durability and precision.
This product is ideal for applications in electronics manufacturing, industrial equipment, test and measurement devices, and other professional electronic assembly settings. Explore more PCB Sockets and related electronic components on EnvMart for your project needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The current rating of this socket is 4.7 A per pin, making it suitable for various low to medium power electronic applications.
It can withstand voltage ratings up to 655 V, allowing it to operate in harsh conditions.
The operating temperature range for this model is from -55°C to 125°C, enabling its use in demanding environments.
This socket uses a through-hole mounting style, which provides secure mechanical and electrical connections to PCBs.
It features a liquid crystal polymer housing and phosphor bronze contacts with gold plating for reliable connectivity and corrosion resistance.
The pitch size of the contacts in this model is 2.54 mm, with a row pitch of 2.5 mm for compact spacing.
This socket has a total of 24 contacts, organized in a 2-row design.
The termination type for this socket is solder tail, which is optimized for PCB soldering processes.
The contact gender of this socket is female, suitable for board-to-board connector systems.
It is suitable for applications in electronics manufacturing, industrial equipment, and test and measurement devices.
The country of origin for this socket is India.
