Norcomp High Density 26 Way Right Angle 2.29 mm Pitch Surface Mount Female D-Sub Connector HDF-R26-213L011

Norcomp HDF-R26-213L011 is a high-density 26 way female D-Sub connector with right angle orientation and 2.29 mm pitch designed for surface mounting applications. It features a rugged polybutylene terephthalate (PBT) housing rated at UL 94V-0 flame resistance and gold plated brass contacts to ensure long-lasting durability and excellent conductivity. The connector shell is made from nickel plated steel providing mechanical strength and corrosion resistance.

Engineered to operate reliably from -25°C to +85°C, this connector can handle currents up to 3A and withstand a voltage rating of 1000V. It includes 4-40 screw mounting hardware to ensure secure fixation during PCB assembly processes. Its IP67 rating confirms protection against dust ingress and water immersion, making it ideal for demanding industrial, telecommunications, and manufacturing applications.

This connector is widely used in electronic component assemblies requiring high pin count connections in compact spaces. Its right angle orientation facilitates neat cable routing and integration into dense electronics boards. The gold plated contacts optimize signal integrity and corrosion resistance, enhancing the reliability of electronic communication.

The connector supports a current rating of 3A for reliable electrical performance. It has a voltage rating of 1000V ensuring solid insulation capability. Constructed with polybutylene terephthalate housing and gold plated brass contacts for durability and corrosion resistance.

Operating temperature range spans from -25°C to 85°C for versatile industrial use. Mounting hardware uses 4-40 screws to secure the component firmly. IP67 rated construction offers protection against dust and water ingress.

The connector shell features nickel plated steel for enhanced mechanical strength. Designed for electronic components, especially suitable for PCB assemblies in industrial and manufacturing environments.
