Texas Instruments Voltage Level Translator 1 Bi-Directional, 24-Pin TSSOP SN74LVC8T245PWR
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | Texas Instruments |
| Height | 1.2mm |
| Length | 7.9mm |
| Model | SN74LVC8T245PWR |
| Mount Type | Surface |
| Output type | 3 State |
| Series | SN74LVC8T |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Pin Count | 24 |
| Number of Elements per Chip | 1 |
| Maximum Supply Voltage | 5.5V |
| Logic Family | LVC |
| Logic Function | Translator |
| Minimum Supply Voltage | 1.65V |
| Maximum High Level Output Current | 32mA |
| Maximum Propagation Delay Time @ CL | 4.4ns |
| Direction Type | Bi-Directional |
| Maximum Low Level Output Current | -32mA |
| Translation | Bi-Directional |
Key Features
- Supports operating voltage from 1.65V to 5.5V for versatile system integration.
- Maximum propagation delay time of 4.4ns ensures high-speed signal translation.
- Bi-directional translation function enables level shifting in both directions.
- Compact surface mount TSSOP package measuring 7.9mm length and 1.2mm height.
- Features 3-state output with maximum low level output current of -32mA and high level output current of 32mA.
- Operates reliably within temperature range of -40°C to 85°C for industrial applications.
- Manufactured in Malaysia with new product condition.
Product Description
Texas Instruments SN74LVC8T245PWR is a voltage level translator designed for reliable bi-directional level shifting between different voltage domains. Featuring a 24-pin TSSOP surface mount package, this IC supports low voltage CMOS logic families (LVC) with a supply voltage range of 1.65V to 5.5V.
The device provides a maximum propagation delay of 4.4 nanoseconds at the specified load capacitance, enabling fast data communication between circuits operating at different voltage levels. Its output design supports three-state operation with maximum low and high level currents of -32mA and 32mA respectively, accommodating various load requirements.
Built for industrial and electronic equipment applications, the SN74LVC8T245PWR operates over a wide temperature range from -40°C to 85°C ensuring robust performance in demanding environments.
It offers a single element per chip functionality specialized for voltage translation with a bidirectional direction type. The package dimensions are 7.9mm in length and 1.2mm in height, making it suitable for compact PCB layouts.
As a product manufactured in Malaysia and supplied in new condition, this voltage level translator is ideal for use in semiconductor logic circuits, embedded systems, and electronic component assemblies requiring efficient signal level management.
Supports bi-directional voltage translation between 1.65V and 5.5V. Compact 24-pin TSSOP surface mount package allows space-saving PCB design. Maximum propagation delay of 4.4ns ensures high-speed operation. Three-state output functionality with 32mA maximum drive current.
Wide operating temperature range from -40°C to 85°C for reliability. Designed for Low Voltage CMOS logic family compatibility. Single element per chip for dedicated translator use. Manufactured in Malaysia, new product.
Applications include industrial electronics, embedded system level shifting, digital logic signal management, and telecommunications equipment. This product is categorized under semiconductor logic ICs, providing advanced voltage translation solutions.
