Samtec FTS Series Vertical Surface Pin Header 12 Contacts 1.27 mm Pitch 2 Row Unshrouded FTS-106-02-F-DV

Samtec FTS-106-02-F-DV is a vertical surface mount pin header designed for reliable board-to-board connections in electronic assemblies. It features 12 gold-plated phosphor bronze contacts arranged in 2 rows with 1.27 mm pitch, offering robust electrical performance.

The pin header housing is made from black liquid crystal polymer which provides high mechanical strength and electrical insulation. Its unshrouded design enables easy inspection and soldering access during PCB assembly.

Operating efficiently within a temperature range of -55°C to 125°C, this connector is suited for industrial, commercial, and laboratory electronic equipment requiring durable connectors under varied environmental conditions.

The 3.4 A current rating supports moderate power applications, while the solder termination ensures a secure and reliable electrical contact to the PCB.

Applications include electronic circuit board assemblies in telecommunications, computing hardware, instrumentation, and other industrial electronic equipment requiring compact, dependable connectors.

Features a vertical orientation suitable for surface mounting. Constructed with phosphor bronze contacts plated with gold for enhanced conductivity and corrosion resistance. Housing is made from durable black liquid crystal polymer for stability and insulation.

Supports an operating temperature range from -55°C to 125°C for diverse environmental conditions. Terminated by solder, ensuring a secure electrical connection on printed circuit boards. Designed for a current rating of 3.4 A to accommodate moderate electrical loads.

The connector system is board-to-board, facilitating compact electronic assemblies. Unshrouded design allows easy access and visibility of contacts. Includes 12 male contacts arranged in 2 rows with a row pitch of 1.27 mm.

Choose Samtec FTS-106-02-F-DV for high-quality, dependable PCB connection needs across industrial, manufacturing, and laboratory environments. Explore more PCB Pin Header components and related electronic connectors available on EnvMart for your assembly projects.
