Samtec TSM Series Vertical Surface Pin Header, 18 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSM-118-01-T-SV

Free Delivery in India | Lowest Global Shipping Charges

Samtec TSM Series Vertical Surface Pin Header, 18 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSM-118-01-T-SV

Name: Samtec TSM Series Vertical Surface Pin Header, 18 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSM-118-01-T-SV
Brand: Samtec
SKU: 105923
Price: 1.84 USD
Availability: InStock



Category PCB Pin Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	475V
Brand	Samtec
Orientation	Vertical
Model	TSM-118-01-T-SV
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	TSM
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold or Tin
Number of Contacts	18
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board
Plating used	Au or Sn over 50 μ" (1.27 μm) Ni

Key Features

Constructed from liquid crystal polymer housing for durability.
Phosphor bronze contacts with gold or tin plating ensure reliable connectivity.
Vertical orientation with unshrouded, surface mount design.
Operates within -55°C to 125°C temperature range.
Designed for a rated voltage of 475V with solder termination type.
Male contact gender suitable for standard PCB connections.
RoHS compliant for environmental safety.
Plating uses gold or tin over 50 micro inches nickel for corrosion resistance.

Product Description

Samtec TSM-118-01-T-SV Vertical Surface Pin Header is a high-quality PCB connector ideal for electronics and electrical applications requiring reliable board-to-board connections. It features 18 male contacts arranged in a single row with 2.54 mm pitch, enabling compact and precise alignment on printed circuit boards.

The housing is made of black liquid crystal polymer, providing excellent insulation and mechanical strength. Contacts are manufactured from phosphor bronze and plated with gold or tin over a 50 micro inch nickel base, ensuring low contact resistance and long-term durability.

This pin header supports surface mount technology (SMT) with a vertical orientation, making it suitable for modern PCB assembly processes. Operating temperature ranges from -55°C to 125°C, accommodating various industrial and commercial environments.

The product is rated for 475 volts and uses solder termination, facilitating secure connections with minimal signal loss. Its unshrouded design allows for easy mating with complementary connectors in diverse electronic systems.

It complies with RoHS standards, reflecting an environmentally responsible manufacturing process. This pin header is widely used in industrial controls, computing devices, telecommunications equipment, and other high-reliability electronic assemblies.

Constructed with liquid crystal polymer housing for enhanced durability. Phosphor bronze contact material for excellent conductivity. Gold or tin plating provides corrosion resistance. Vertical, unshrouded surface mount design compatible with automated assembly.

Suitable for operating temperatures from -55°C to 125°C. Rated for 475 volts ensuring safe electrical performance. Solder termination for reliable PCB attachment. Compliant with RoHS environmental standards. Explore a broad range of connectors and PCB components at EnvMart for industrial, manufacturing, and electronic engineering applications.

Explore more products in our PCB Pin Header category.
