Samtec Pin Header, Straight Surface Mount, 20 Contacts, 2 mm Pitch, 2 Row, Unshrouded TMM-110-01-S-D-SM-A

Samtec TMM-110-01-S-D-SM-A is a high-quality pin header designed for electronic PCB connections with a straight orientation and surface mount type. It features 20 male contacts arranged in 2 rows with a standard 2 mm pitch, suitable for compact and precise board-to-board assembly needs.

The housing is made from black liquid crystal polymer, providing effective insulation and stability under thermal stress. Contact material comprises phosphor bronze with gold plating, delivering low resistance and durability for signal integrity. The pin header operates at a maximum voltage of 281 V and supports current up to 3.2 A per contact, making it ideal for moderate power electronic applications.

This header is unshrouded, enabling easy access for solder termination on printed circuit boards. It operates reliably over a temperature range from -55°C to 125°C, accommodating a wide variety of industrial and electronic environments.

Its surface mount design facilitates automated placement and soldering processes, enhancing manufacturing efficiency and assembly precision. The product is RoHS compliant ensuring environmentally safe manufacturing and usage standards.

The Samtec TMM series pin header is commonly used in industrial electronics, instrumentation, manufacturing equipment, telecommunications, and other applications requiring dependable board interconnections.

2 mm pitch spacing for accurate connector fitting. 20 male contacts in 2 rows with gold-plated phosphor bronze material. Liquid crystal polymer housing for stable insulation. Surface mount type allows easy PCB integration.

Supports 3.2 A current and 281 V voltage rating. Operating temperature range from -55°C to 125°C. Solder termination type ensures strong electrical connections. Explore more in the PCB Pin Header category to find complementary parts and accessories for your electronic designs at EnvMart.
