Samtec TSM Series Right Angle Surface Pin Header, 25 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSM-125-02-L-SH

Samtec TSM-125-02-L-SH is a right angle surface pin header from the TSM Series designed for reliable electronic interconnections. The connector features 25 gold-plated phosphor bronze contacts arranged in a single row with a 2.54 mm pitch. Its liquid crystal polymer housing provides mechanical stability and high-temperature resistance, making it suitable for industrial-grade PCB applications.

This surface mount pin header is rated for a current of 7A and supports a voltage of 475V, accommodating demanding electrical requirements. Its operational temperature range spans from -55°C to 125°C, allowing usage in environments with varying thermal conditions. The connector employs solder termination, ideal for modern SMT assembly processes, and includes male contact gender with an unshrouded design for accessible connections.

The 8.13 mm mating pin length ensures secure engagement with matching sockets, suitable for board-to-board and wire-to-board connector systems. Typical industrial applications include electronics manufacturing, telecommunications, computing hardware, and control systems requiring durable and precise PCB headers.

Right angle orientation for versatile board mounting. High-quality liquid crystal polymer housing guarantees mechanical strength. Gold plating on contacts reduces corrosion and enhances longevity. Compatible with various mating socket types for flexibility.

Supports high current and voltage ratings for demanding circuits. Wide operating temperature range ensures reliability in harsh conditions. Solder termination supports surface mount technology (SMT) manufacturing. Unshrouded, male contacts facilitate easy mating connections.

Single row design with 25 contacts meets diverse interconnection needs. Ideal for industrial, telecommunications, computing, and electronics assembly use cases.

This product facilitates efficient and reliable electronic connections essential for multiple industrial and commercial applications. Explore more PCB Pin Headers and connectors at EnvMart to suit diverse project requirements.
