Samtec BSW Series Straight Surface PCB Socket 20-Contact 2 Row 2.54 mm Pitch Solder BSW-110-04-S-D

The Samtec BSW-110-04-S-D is a straight surface-mounted PCB socket designed for board-to-board connector applications. It features 20 contact points arranged in 2 rows with a 2.54 mm pitch, making it suitable for a variety of high-performance electronics requiring reliable interconnection solutions.

This socket’s housing is made from black thermoplastic, providing excellent electrical insulation and mechanical stability. The contact material is phosphor bronze, known for its strength and corrosion resistance, plated with gold over tin to enhance conductivity and prevent oxidation.

Engineered to operate between -55°C and 125°C, this socket performs reliably under varying environmental conditions, making it ideal for industrial, telecommunications, computing, and other electronic manufacturing applications.

The BSW series is RoHS compliant, ensuring adherence to environmentally responsible manufacturing practices. Its surface mount design allows for easy and stable placement on printed circuit boards, facilitating efficient assembly processes.

This product is commonly used in applications requiring durable board-to-board connection points with secure electrical contact and resistance to mechanical stresses. This PCB socket has a straight orientation for surface mounting applications.

Constructed with black thermoplastic housing material for excellent insulation. Phosphor bronze contact material with gold over tin plating ensures durable and reliable connections. Operating temperature ranges from -55°C to 125°C for robust performance.

Complies with RoHS standards for environmentally friendly usage. Suited for board-to-board interconnections in electronic devices and equipment. Part of the BSW series known for precise and stable socket solutions. Explore more high-quality PCB Sockets and electronic components at EnvMart to support your industrial, laboratory, manufacturing, or electronic design needs.
