Samtec Vertical Surface PCB Socket 5-Contact 2 Row 2 mm Pitch Press-in CLT-105-02-L-D-A-K-TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Vertical |
| Model | CLT-105-02-L-D-A-K-TR |
| Mount Type | Surface |
| Housing Material | LCP |
| Contact Material | Phosphor Bronze |
| Series | CLT |
| Termination Type | Press-in |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 5 |
Key Features
- Constructed with a rugged Liquid Crystal Polymer housing material for durability.
- Equipped with phosphor bronze contacts plated with gold for reliable conductivity.
- Supports vertical orientation suitable for top and bottom entry applications.
- Operates within a temperature range from -55°C to 125°C for diverse environments.
- Designed to meet RoHS compliance ensuring environmental safety.
- Ideal for use in electronic assemblies requiring dual-wipe contact system for pass-through connectivity.
- Surface mount type ensuring secure PCB integration.
- Part of the CLT series with a proven track record for quality and performance.
Product Description
The Samtec CLT-105-02-L-D-A-K-TR is a high-quality vertical surface PCB socket designed for electronic components requiring robust and reliable connections. Featuring 5 contacts arranged in 2 rows with a 2 mm pitch, this socket uses a press-in termination method to ensure secure and dependable mounting on printed circuit boards.
The housing material is made of Liquid Crystal Polymer (LCP), offering rugged durability and stability under various operating conditions. Phosphor bronze contacts finished with gold plating provide excellent electrical conductivity and corrosion resistance, enhancing long-term performance.
This PCB socket supports vertical orientation and is suitable for applications requiring both top and bottom entry connectivity. It operates effectively in temperatures ranging from -55°C to 125°C, making it suitable for harsh industrial and electronic environments.
Samtec's CLT series sockets utilize the Tiger claw dual-wipe contact system, facilitating pass-through connections that improve signal integrity. The surface mount design allows for easy integration into printed circuit board layouts, supporting efficient assembly and manufacturing processes.
Ideal for industrial, electronic manufacturing, and laboratory applications, this socket provides a reliable interface for electronic components in demanding operational contexts. It complies with RoHS standards, ensuring it meets environmental and safety regulations.
5 contacts arranged in 2 rows with a 2 mm pitch. Press-in termination for secure PCB mounting. Rugged LCP housing material designed for durability. Gold-plated phosphor bronze contacts for enhanced conductivity. Supports vertical orientation with top and bottom entry options.
Operates within a wide temperature range from -55°C to 125°C. Dual-wipe Tiger claw contact system allows reliable pass-through connections. Surface mount type, part of the CLT series ensuring consistent quality.
For those seeking durable and efficient PCB sockets for various electronic applications, the Samtec CLT-105-02-L-D-A-K-TR offers outstanding electrical and mechanical performance. Browse additional Samtec products and other PCB Sockets at EnvMart for comprehensive electronic component solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a 2 mm pitch with 5 contacts arranged in 2 rows.
It operates effectively at a maximum temperature of 125°C.
The housing is made of Liquid Crystal Polymer (LCP), and the contacts are phosphor bronze plated with gold.
Yes, it meets RoHS compliance, ensuring it adheres to environmental safety regulations.
It uses a press-in termination method for secure mounting on printed circuit boards.
This socket supports vertical orientation, suitable for both top and bottom entry applications.
The minimum operating temperature is -55°C, allowing it to function in diverse environments.
It is designed as a surface mount type, facilitating easy integration into PCB layouts.
This model is part of the CLT series, which is known for its quality and performance in electronic applications.
The dual-wipe Tiger claw contact system facilitates reliable pass-through connections, improving signal integrity.
The country of origin for this model is India.
It is ideal for use in electronic assemblies requiring robust connections, including industrial and laboratory applications.
