SMC Pneumatic Compact Cylinder 20mm Bore, 25mm Stroke, Double Acting Aluminium Alloy Body CQUB20-25

The SMC CQUB20-25 pneumatic compact cylinder is a specialised double acting cylinder with a 20mm bore and 25mm stroke, crafted with an aluminium alloy body for enhanced durability and lightweight construction. It is part of the CQU series, known for space-saving design and power efficiency within automation and industrial applications.

This compact cylinder features a rubber cushioning system which reduces impact shocks and increases the lifespan of the device while enabling smooth operation at a maximum operating pressure of 0.7 MPa. It supports a wide operating temperature range from -10 degrees Celsius to 70 degrees Celsius, making it suitable for diverse industrial environments including manufacturing, automation, and processing systems.

The through hole mounting type provides versatility for different assembly configurations while the single rod type with female piston rod thread follows metric standards ensuring compatibility with various pneumatic setups. The cylinder length is compact at 74mm with a height of 47mm and a width of 22mm, optimizing installation space.

Weighing just 144 grams, this cylinder offers a lightweight solution while maintaining performance. The CQUB2 series to which this belongs is about 15% more efficient and up to 36% lighter than previous versions, ideal for machine builders seeking power-saving and space-efficient pneumatic components.

Compact and lightweight aluminium alloy body for easy installation and maintenance. Double acting operation for precise pneumatic control. Rubber cushioning to reduce impact and extend cylinder life. Maximum operating pressure up to 0.7 MPa for reliable performance.

Operating temperature range from -10°C to 70°C suitable for diverse environments. Through hole mount type enables flexible mounting options. Single rod type with female piston rod thread of metric standard. Stroke length of 25mm with overall cylinder length of 74mm.

Compact dimensions with height 47mm and width 22mm. Weight of approximately 144 grams ensuring lightweight design.

This pneumatic compact cylinder is well suited for industrial automation, mechanical machinery, manufacturing processes, and fluid power systems. It offers design engineers a reliable, efficient, and space saving pneumatic actuator option.

Explore more Pneumatic Cylinders and actuators in the Industrial Tools & Equipment segment at EnvMart.
