Samtec SSQ Series Straight Through Hole PCB Socket 8-Contact 1 Row 2.54 mm Pitch 655V 6.3A SSQ-108-03-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 655V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 6.3A |
| Model | SSQ-108-03-T-S |
| Mount Type | Through Hole |
| Special Features | Standard and low insertion force contacts with .025" (0.635 mm) square tails for self-nesting applications |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | SSQ |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 8 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Contact System | Tiger Buy™ |
Key Features
- Supports a current rating of 6.3A at 655V voltage for robust electrical performance.
- Constructed with a housing made of durable Liquid Crystal Polymer for high temperature resistance.
- Features through-hole solder termination with a straight orientation for secure mounting.
- Contact system utilizes Tiger Buy™ technology with bronze female contacts plated with tin.
- Operates reliably in temperatures ranging from -55°C to 105°C, suitable for various industrial environments.
- Standard and low insertion force contacts have .025" (0.635 mm) square tails for self-nesting applications.
- The series supports single, double, and triple row connectors up to 150 pins for scalability.
- Designed for vertical and right-angle board-to-board connector applications with a 2.54 mm pitch.
Product Description
Samtec SSQ-108-03-T-S is a premium PCB socket from the SSQ Series designed as a straight through hole connector with 8 contacts arranged in a single row. It offers a 2.54 mm pitch and supports board-to-board connections with a reliable current rating of 6.3A and voltage rating of 655V, ensuring safety and performance in electronic systems.
The housing is made of liquid crystal polymer, providing excellent durability and resistance to high temperatures between -55°C and 105°C. The connector uses bronze female contacts plated with tin, incorporating Tiger Buy™ contact system technology to maintain electrical integrity and reduce wear from mating cycles.
This socket features through-hole solder termination and a straight orientation, making it suitable for vertical insertion on printed circuit boards. The standard and low insertion force contacts include .025" square tails that facilitate self-nesting applications, enhancing assembly efficiency.
With the capability to be configured for single, double, and triple row connectors up to 150 pins, the SSQ series accommodates a wide range of electronic designs. Due to its robust material construction and electrical characteristics, it is ideal for industrial electronics, power distribution, telecommunications, and general-purpose PCB applications.
Supports 6.3A current and 655V voltage for demanding environments. Durable liquid crystal polymer housing withstands wide temperature ranges. Tiger Buy™ contact technology for reliable female contact performance. Through-hole solder termination provides mechanical stability.
Standard and low insertion force contacts with self-nesting tails improve usage. Applicable for vertical and right-angle orientations and board-to-board systems.
This product is New and made in India, ensuring quality and conformity with general industrial standards. Discover more products in the PCB Socket category at EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 6.3A and a voltage rating of 655V, making it suitable for demanding electrical applications.
It operates reliably in temperatures ranging from -55°C to 105°C, suitable for various industrial environments.
The housing is constructed from liquid crystal polymer, providing high temperature resistance and durability.
The SSQ-108-03-T-S features 8 contacts arranged in a single row.
It utilizes through-hole solder termination, which provides mechanical stability during installation.
The pitch of the contacts is 2.54 mm, which is standard for many PCB applications.
It includes standard and low insertion force contacts with .025" (0.635 mm) square tails for self-nesting applications, enhancing assembly efficiency.
This socket supports a board-to-board connector system, making it versatile for various electronic designs.
The contacts are made of bronze and are plated with tin to ensure reliable electrical performance.
It is ideal for industrial electronics, power distribution, telecommunications, and general-purpose PCB applications.
This product is manufactured in India, ensuring quality and conformity with general industrial standards.
This model features a straight orientation, making it suitable for vertical insertion on printed circuit boards.
