Samtec SSQ Series Straight Through Hole PCB Socket 8-Contact, 2 Row, 2.54 mm Pitch SSQ-104-01-L-D

Samtec SSQ-104-01-L-D is a high-quality straight through hole PCB socket designed for demanding electronic applications.

The housing is made from liquid crystal polymer in black, offering excellent mechanical strength and thermal stability. The contacts are female and made of phosphor bronze, plated with 0.25 µm gold to ensure superior conductivity and corrosion resistance.

This socket supports a current rating of 6.3 A, with a voltage rating of 655 V, and operates efficiently across a wide temperature range from -55°C up to 125°C, making it suitable for industrial, electronic manufacturing, and laboratory environments where reliable electrical connections are essential.

The design incorporates a square tail socket strip with low insertion force for ease of assembly in surface mount and through hole applications. The 2.5 mm row pitch and 2.54 mm contact pitch provide precise spatial configuration for compact PCB layouts and high-density electronic assemblies.

Liquid crystal polymer housing ensures durability and thermal resistance. Phosphor bronze gold-plated female contacts provide excellent electrical conduction. Rated for 6.3 A current and 655 V voltage application. Temperature operating range from -55°C to 125°C accommodates varied environments.

Designed for through hole mounting and board-to-board connector systems. Standard low insertion force contacts with self-nesting square tails. 8 contacts and 2 row configuration optimize connection density on PCBs.

This Samtec PCB socket is widely used in electronics manufacturing, industrial hardware, prototyping labs, and other electrical component assemblies requiring dependable and precise connector solutions. Explore related PCB Sockets and connectors for comprehensive electronic assembly needs on EnvMart.
