STMicroelectronics 1-Element Bi-Directional TVS Diode Surface Mount DO-214 Package 600W SMBJ58CA-TR

STMicroelectronics SMBJ58CA-TR is a high-quality 1-element bi-directional TVS diode designed for transient voltage suppression in electronic circuits. Rated at 600 Watts peak pulse power dissipation, this surface-mount device comes in a DO-214 package, ensuring easy integration into PCB assemblies. It provides excellent protection against electrostatic discharge and transient voltage spikes, making it suitable for industrial, electronic, and power management applications.

The diode features a single-element configuration with bi-directional operation, allowing it to clamp voltage surges effectively in both directions. The device offers a minimum breakdown voltage of 64.4 V and a maximum reverse stand-off voltage of 58 V, ensuring reliable suppression of surges up to these levels. Its maximum peak pulse current rating of 33 A enables it to withstand heavy transient currents without damage.

With an operating temperature range from -55°C to 150°C, the SMBJ58CA-TR is reliable for use in harsh environments, including industrial and automotive electronic applications. Its low maximum reverse leakage current of 200 nA reduces power losses during normal operation. The compact dimensions (4.6 mm length, 3.95 mm width, 2.45 mm height) support space-saving designs in high-density circuit boards.

It is ideal for use in electronic products requiring protection from voltage spikes, such as power supplies, telecommunications, industrial controls, and consumer electronics. Single element, bi-directional diode for ESD and transient voltage protection.

Peak pulse power dissipation rating of 600 Watts. Minimum breakdown voltage of 64.4 Volts and maximum reverse stand-off voltage of 58 Volts. Compact DO-214 surface mount package designed for PCB integration. Operating temperature range from -55°C to 150°C for demanding environments.

Maximum peak pulse current of 33 Amperes to handle high surge currents. Low maximum reverse leakage current of 200 nanoamperes minimizes power loss. Small footprint with 4.6 mm length, 3.95 mm width, and 2.45 mm height. Test current of 1 mA enables reliable device testing and quality assurance.

This product is highly suitable for industrial, telecommunications, power management, and consumer electronics fields requiring surge protection. Explore EnvMart's extensive range of Semiconductor TVS Diodes for more solutions from leading manufacturers.
