STMicroelectronics Current Sensing Amplifier Single Channel 8-Pin SO-8 Package TSC2012HYDT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.75mm |
| Length | 5mm |
| Model | TSC2012HYDT |
| Mount Type | Surface |
| Series | TSC2012 |
| Maximum Operating Temperature | 150°C |
| Package Type | SO-8 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
| Supply Current | 5mA |
| GBP - Gain Bandwidth Product | 490kHz |
| CMRR - Common Mode Rejection Ratio | 80dB |
Key Features
- Operates with a single power supply voltage from 2.7 to 5.5 volts.
- Offers a high common mode rejection ratio (CMRR) of 80 dB for accurate sensing.
- Consumes a low supply current of only 5 mA to ensure energy efficiency.
- Designed to operate reliably within a temperature range of -40 to 150°C.
- Gain bandwidth product (GBP) of 490 kHz enables precise and fast signal amplification.
- Complies with the automotive standard AEC-Q100 for quality and reliability.
- Compact surface mount SO-8 package with 8 pins facilitates easy PCB integration.
- Precision offset voltage of ±200 μV maximum minimizes measurement error.
Product Description
STMicroelectronics TSC2012HYDT is a high-precision current sensing amplifier designed for industrial and automotive applications requiring accurate bidirectional current measurement. This device operates on a single power supply voltage ranging from 2.7 V up to 5.5 V, making it suitable for low-voltage systems.
Featuring an 8-pin SO-8 surface mount package, it offers compactness and ease of integration on printed circuit boards. The amplifier delivers a wide common mode voltage range from -20 V to +70 V, enabling it to sense current via a shunt resistor over a broad voltage spectrum.
With a gain bandwidth product of 490 kHz and a high common mode rejection ratio (CMRR) of 80 dB, the TSC2012HYDT ensures precise and noise-resistant current measurement. The supply current is low at 5 mA, contributing to efficient energy use in embedded systems.
The device maintains stable operation across automotive temperature ranges from -40°C to 150°C, and complies with the AEC-Q100 automotive quality standard for enhanced reliability. Offset voltage is minimized to ±200 μV with offset drift limited to 5 μV/°C to reduce measurement errors caused by temperature changes.
Single 2.7 to 5.5 V supply voltage operation. Wide common mode input voltage range from -20 V to +70 V. High precision offset voltage and low offset drift for accuracy. 8-pin SO-8 compact surface mount packaging. AEC-Q100 automotive qualification ensures durability.
Low 5 mA supply current for power efficiency. Gain bandwidth product of 490 kHz for responsive sensing. Temperature operating range -40°C to 150°C.
This current sensing amplifier is ideal for use in automotive electronics, industrial machinery, power management, and embedded systems where accurate current monitoring is critical. The robust design and compliance with automotive standards make it suitable for demanding environments. Enhance your PCB designs with the precision and reliability offered by STMicroelectronics TSC2012HYDT current sensing amplifier.
Explore more quality semiconductor amplifiers and electronic components at EnvMart for reliable industrial and automotive solutions.
Explore more products in our Current Sensing Amplifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model operates with a single power supply voltage ranging from 2.7 V to 5.5 V.
It features a wide common mode input voltage range from -20 V to +70 V.
The gain bandwidth product of this unit is 490 kHz, enabling precise and fast signal amplification.
The maximum operating temperature is 150°C, making it suitable for high-temperature applications.
It consumes a low supply current of only 5 mA, contributing to energy efficiency.
The amplifier offers a high common mode rejection ratio (CMRR) of 80 dB for accurate sensing.
It has a precision offset voltage of ±200 μV maximum, which minimizes measurement error.
This model is housed in a compact 8-pin SO-8 surface mount package, facilitating easy PCB integration.
It complies with the AEC-Q100 automotive quality standard, ensuring reliability in automotive applications.
The minimum operating temperature is -40°C, allowing for reliable performance in low-temperature environments.
This unit is a single channel current sensing amplifier, designed for accurate bidirectional current measurement.
The dimensions are 5 mm in length and 1.75 mm in height, suitable for compact applications.
