Taiwan Semiconductor 1-Element Bi-Directional TVS Diode 600 W 2-Pin DO-15 P6KE68CA
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 3.6mm |
| Brand | Taiwan Semiconductor |
| Height | 3.6mm |
| Length | 7.6mm |
| Model | P6KE68CA |
| Width | 3.6mm |
| Mount Type | Through Hole |
| Series | P6KE |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-15 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 92V |
| Automotive Standard | AEC-Q101 |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 64.6V |
| Maximum Reverse Stand-off Voltage Vwm | 58V |
| Peak Pulse Power Dissipation Pppm | 600W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 6.8A |
| Maximum Reverse Leakage Current | 1μA |
Key Features
- Single diode configuration designed for bi-directional voltage suppression.
- Peak pulse power dissipation of 600 W ensures robust surge protection.
- Clamping voltage of 92 V and maximum reverse stand-off voltage of 58 V.
- Mounted through-hole DO-15 package with 2 pins for easy PCB integration.
- Wide operating temperature range from -55°C to 175°C supports harsh environments.
- Low maximum reverse leakage current of 1μA for efficient performance.
- Complies with automotive standard AEC-Q101 for reliable automotive applications.
Product Description
Taiwan Semiconductor P6KE68CA is a 1-element bi-directional transient voltage suppression (TVS) diode, designed to protect sensitive electronic circuits from voltage spikes and transient surges. It features a single diode configuration in a 2-pin DO-15 through-hole package, providing durable protection up to 600 W peak pulse power dissipation.
This TVS diode is engineered for bi-directional voltage suppression with key specifications including a minimum breakdown voltage of 64.6 V, clamping voltage of 92 V, and maximum reverse stand-off voltage of 58 V. It maintains a low maximum reverse leakage current of 1μA, optimizing efficiency in sensitive circuits.
The component operates reliably across a broad temperature range, from -55°C up to 175°C, making it suitable for industrial, automotive, and electronic manufacturing applications. The diode conforms to the AEC-Q101 automotive standard, ensuring compliance with demanding automotive quality and reliability requirements.
The P6KE68CA's compact dimensions (3.6 mm diameter and height, 7.6 mm length) and through-hole mounting simplify assembly on printed circuit boards. It is ideal for use in power supply protection, industrial controls, and communication equipment to prevent transient voltage damage during surges or electrostatic discharge events.
Single diode, bi-directional TVS for transient voltage protection. High peak pulse power dissipation of 600 W. Wide temperature operation from -55°C to 175°C. Low reverse leakage current for minimal power loss. Automotive-grade AEC-Q101 standard compliance.
Compact DO-15 through-hole package with 2 pins. Suitable for industrial, automotive, and electronic manufacturing.
Choose Taiwan Semiconductor P6KE68CA 1-Element Bi-Directional TVS Diode for reliable, high-performance voltage transient protection in demanding technical applications. Explore additional semiconductor components and electronics at EnvMart for your industrial and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of the P6KE68CA diode is 600 W, providing robust surge protection for sensitive circuits.
The clamping voltage for the P6KE68CA is 92 V, which helps protect against voltage spikes.
The maximum reverse stand-off voltage of this diode is 58 V, ensuring it can handle transient surges effectively.
This model operates within a wide temperature range from -55°C to 175°C, making it suitable for harsh environments.
The maximum reverse leakage current for the P6KE68CA is 1μA, which contributes to its efficiency in sensitive applications.
The diode is housed in a DO-15 package type, designed for through-hole mounting on printed circuit boards.
This model features a 2-pin configuration, facilitating easy integration into electronic circuits.
The P6KE68CA complies with the AEC-Q101 automotive standard, ensuring reliability for automotive applications.
The minimum breakdown voltage of this diode is 64.6 V, which is critical for its protective functionality.
The maximum peak pulse current for the P6KE68CA is 6.8 A, allowing it to handle significant transient events.
The dimensions of this diode are 3.6 mm in diameter and height, and 7.6 mm in length, making it compact for various applications.
This diode is suitable for applications in power supply protection, industrial controls, and communication equipment to prevent transient voltage damage.
