Molex KK 254 Series Right Angle Through Hole Pin Header, 7 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 22-05-3071

Free Delivery in India | Lowest Global Shipping Charges

Molex KK 254 Series Right Angle Through Hole Pin Header, 7 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 22-05-3071

Name: Molex KK 254 Series Right Angle Through Hole Pin Header, 7 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 22-05-3071
Brand: Molex
SKU: 101328
Price: 0.35 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Molex
Orientation	Right Angle
Mount Type	Through Hole
Housing Material	Nylon
Contact Material	Brass
Series	KK 254
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Tin
Number of Contacts	7
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	3.58mm

Key Features

The pin header is constructed with brass contacts plated in tin for reliable conductivity.
It has a nylon UL 94V-0 white housing material ensuring durability and insulation.
This header mounts through a hole and supports wire-to-board connection system.
Designed for solder termination with a tail pin length of 3.58 mm for firm attachment.
It operates in temperature ranges from -40°C to 105°C suitable for various electronics applications.
The contact gender is male, with the header being unshrouded and allowing end-to-end stacking.
It supports a voltage rating of 250V, ideal for low-voltage electronic assemblies.
The right angle orientation facilitates compact PCB layouts and improved signal routing.

Product Description

Molex 22-05-3071 KK 254 Series Right Angle Through Hole Pin Header is a precision electronic component designed for robust wire-to-board connections. Featuring 7 male contacts with a 2.54 mm pitch arranged in a single row, this unshrouded header is ideal for tight PCB spaces requiring right angle mounting.

The pin header’s brass contacts come with tin plating to provide reliable electrical conductivity and resistance to corrosion. The housing is manufactured from UL 94V-0 rated nylon in white, ensuring excellent electrical insulation and mechanical strength for industrial and commercial electronics applications.

This component mounts through holes on printed circuit boards and supports solder termination, making it suitable for durable and long-lasting assemblies. The tail pin length of 3.58 mm assures consistent and secure solder joints during manufacturing.

Engineered for a temperature range from -40°C to 105°C, this header accommodates diverse environmental conditions, including industrial control systems, instrumentation, and consumer electronics.

The unshrouded design allows for easy access and end-to-end stacking of headers, increasing modularity in system design. Its right angle orientation aids compact PCB design and efficient routing of signals.

The header is composed of brass contacts plated with tin for optimal conductivity. Nylon housing provides electrical insulation and mechanical robustness. Mounts through hole with solder termination for secure connection.

Operates reliably in temperatures from -40°C to 105°C. Designed for 250V applications in low-voltage electronics. Right angle design supports space-saving PCB layouts. Unshrouded style allows end-to-end stacking capability.

This Molex KK 254 pin header suits applications in industrial electronics, telecommunications, computer hardware, and other sectors requiring dependable PCB interconnects. Explore more electronics components and connectors in the Electronics Components category at EnvMart.
