ASSMANN WSW D-Sub Connector 25 Way Right Angle 2.54 mm Pitch Cable with PCB Male A-DSF 25LPIII/FP
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 500V |
| Brand | ASSMANN WSW |
| Orientation | Right Angle |
| Current | 5A |
| Model | A-DSF 25LPIII/FP |
| Mount Type | Cable |
| Housing Material | Plastic |
| Contact Material | Brass |
| Series | A-DSF |
| Mounting Hardware | PCB |
| Termination Type | IDC |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Pitch | 2.54mm |
| Standards/Approvals | UL94V-0, DIN 41652 |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 25 |
| Contact Gender | Male |
| Connector Gender | Male |
| Connector Type D | D-Sub |
| D-Sub Shell Size | 15 |
Key Features
- The connector has 25 contacts for reliable electrical connection.
- Right angle orientation optimizes space in PCB layout.
- Termination type is Insulation Displacement Contact (IDC) for efficient assembly.
- Contact material is brass with gold over nickel plating for corrosion resistance.
- Plastic housing material ensures lightweight and durability.
- Operating temperature range is from -55°C to 125°C allowing use in extreme conditions.
- Conforms to UL94V-0 and DIN 41652 standards for safety and compatibility.
- Designed for cable mounting with PCB male connector gender and D-Sub shell size 15.
Product Description
ASSMANN WSW A-DSF 25LPIII/FP D-Sub Connector is a high-quality right angle 25 way cable connector engineered for reliable PCB connectivity. It features a 2.54 mm pitch and incorporates insulation displacement contact (IDC) termination technology for quick and secure wire installation.
This connector supports a current rating of 5A and a voltage rating of 500V, making it suitable for various electronic and industrial applications where stable and robust electrical connections are essential.
The connector housing is constructed from durable plastic, while the contact pins are brass plated with gold over nickel to provide excellent corrosion resistance and long service life. Its right angle orientation with a D-Sub shell size 15 allows efficient use of PCB space and easy integration into assemblies.
Operating reliably across a wide temperature range of -55°C to 125°C, this connector meets UL94V-0 flammability and DIN 41652 standards, ensuring safety and compliance in demanding environments.
This product is ideal for use in electronics manufacturing, industrial control systems, automation equipment, and other applications requiring quality interconnect solutions. The connector provides 25 contacts for effective signal transmission and power transfer.
The IDC termination type enables fast and reliable cable termination without soldering. High operating temperature range allows performance in harsh conditions. Gold over nickel plating enhances conductivity and prevents corrosion.
Right angle cable mounting with PCB male interface optimizes assembly design. Meets important safety and industry standards for connector reliability. Plastic housing promotes durability with reduced weight. Manufactured in China under rigorous quality controls.
Suitable for electronic component, power connector, and cable assemblies. Explore more connectors and electronic components in the ASSMANN WSW range available at EnvMart for your industrial and manufacturing needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this connector is 500V, making it suitable for various electronic applications.
This model has a current rating of 5A, which allows it to handle significant electrical loads.
It operates reliably within a temperature range of -55°C to 125°C, suitable for extreme conditions.
The connector utilizes insulation displacement contact (IDC) termination, allowing for quick and efficient wire installation without soldering.
This connector features 25 contacts, facilitating effective signal transmission and power transfer.
The housing is made of plastic, while the contact pins are brass with gold over nickel plating for corrosion resistance.
It conforms to UL94V-0 and DIN 41652 standards, ensuring safety and compatibility in various applications.
The pitch size for this model is 2.54 mm, which is standard for many electronic applications.
This connector has a right angle orientation, optimizing space in PCB layouts for easier integration.
It is designed for cable mounting with a PCB male connector gender, making it suitable for various assemblies.
This connector is manufactured in China under rigorous quality controls, ensuring reliable performance.
It is ideal for use in electronics manufacturing, industrial control systems, and automation equipment, requiring quality interconnect solutions.
