Molex Micro-Fit 3.0 Series Right Angle Through Hole PCB Header 8 Contacts 3 mm Pitch 1 Row Shrouded 43650-0800
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 5A |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Brass |
| Series | Micro-Fit 3.0 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3mm |
| Contact Plating | Tin |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- High current carrying capacity up to 5 amperes in a compact footprint.
- Constructed with liquid crystal polymer housing supporting high temperature soldering.
- Right angle orientation with through hole mounting ensures secure PCB connection.
- Shrouded design with snap-in plastic peg PCB locks prevents accidental disconnection.
- Contacts made of brass with tin plating for reliable solder termination.
- Suitable for military, solar power, consumer electronics, telecommunications, and medical devices.
- Operating temperature range from -40°C to 105°C ensures performance in harsh environments.
- Compatible with both through hole and SMT processes reducing manufacturing costs.
Product Description
Molex 43650-0800 Micro-Fit 3.0 Series Right Angle Through Hole PCB Header is a shrouded male connector featuring 8 contacts arranged in a single row with a 3 mm pitch designed for wire-to-board connection systems.
This PCB header supports a current rating of 5A and operates at a voltage of 250 volts. The housing is made from high-temperature liquid crystal polymer to withstand IR reflow soldering temperatures up to 265°C, ensuring durability in industrial manufacturing processes.
With its right angle orientation and through hole mounting type, it offers robust mechanical and electrical connection, enhanced by snap-in plastic peg PCB locks that secure the header on the PCB and prevent accidental disconnection. The fully isolated contacts reduce electrical arcing and improve reliability.
The brass contacts plated with tin provide corrosion resistance and reliable soldering characteristics. The positive latching mechanism incorporated via a locking ramp on the housing delivers secure mating for stable electrical performance.
This connector is suitable for a wide range of applications including military commercial off-the-shelf solutions, solar power systems, consumer appliances such as dryers and refrigerators, data communication devices including routers and servers, telecommunications equipment, medical instrumentation, and gaming terminals.
High current carrying capacity up to 5A in a compact form factor. Liquid Crystal Polymer housing for high-temperature IR soldering tolerance. Right angle, through hole mount design with positive latching. Shrouded with snap-in plastic peg PCB locks for secure placement and connection.
Brass contacts with tin plating for durability and solderability. Suitable for use in harsh and varied industrial environments. Fully isolated contacts prevent arcing for reliable electrical performance. Compatible with SMT process to reduce manufacturing complexity and cost.
Wide range of industrial and commercial applications supported.
Explore Molex Micro-Fit 3.0 Series and other PCB header solutions in the Electronics Components category at EnvMart for reliable and precise power connector products suited to your industrial needs.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 5 amperes, making it suitable for high current applications.
The voltage rating for this connector is 250 volts, ensuring compatibility with various electrical systems.
The housing is made from liquid crystal polymer, while the contacts are constructed from brass with tin plating for reliable solder termination.
It operates within a temperature range of -40°C to 105°C, allowing for performance in harsh environments.
This connector features 8 contacts arranged in a single row, designed for efficient wire-to-board connections.
It utilizes a through hole mounting type, providing a secure connection to the PCB.
Yes, it features a positive latching mechanism with a locking ramp on the housing to ensure secure mating and stable electrical performance.
Yes, it is compatible with both through hole and SMT processes, which can help reduce manufacturing costs.
The pitch of the contacts is 3 mm, allowing for compact arrangements on PCBs.
It is suitable for a wide range of applications including military, solar power, telecommunications, medical devices, and consumer electronics.
This model has a right angle orientation, which can be beneficial for space-constrained designs.
The country of origin for this product is China.
