Molex SL Series Straight Through Hole PCB Header 10 Contact 2.54 mm Pitch 1 Row Shrouded 70543-0044

Molex 70543-0044 SL Series Straight Through Hole PCB Header is a high-quality connector designed for wire-to-board applications, featuring 10 contacts with a 2.54 mm pitch arranged in a single row. The shrouded, straight orientation header ensures secure and reliable connections in electronic assemblies.

The connector housing is made from glass filled polyester providing excellent insulation and mechanical strength, suitable for industrial and commercial electronics. Contact points are made from phosphor bronze with protective tin plating to resist wear and corrosion, ensuring durability through repeated mating cycles.

This PCB header operates efficiently within temperatures from -40°C up to 105°C and supports up to 3 amps of current at voltages up to 250V, making it suitable for various demanding electronics and instrumentation applications including industrial controls and communication equipment.

The shrouded design enhances safety by protecting contacts from accidental damage and short circuits. Mounting is designed for through-hole soldering, offering robust mechanical securing of the connector to printed circuit boards.

Supports a maximum current of 3A for reliable electrical performance. Constructed with glass filled polyester housing for durability and insulation. Features phosphor bronze contact material plated with tin for corrosion resistance.

Designed for through hole mounting with a straight orientation and shrouded contacts. Operates reliably in temperatures ranging from -40°C to 105°C. Termination via soldering ensures secure connection to PCB. Contact tail pin length is 3.3 mm with mating pin length of 6.1 mm.

Rated for 250V to support various electronic applications. Ideal for wire-to-board connector system in electronic and electrical devices.

This PCB header is widely used in industrial electronics, telecommunications, manufacturing equipment, and other electrical applications requiring dependable PCB connectivity. Molex’s SL Series ensures performance consistency and ease of integration in electronic system designs.
