Samtec TFM Series Straight Through Hole PCB Header 40 Contacts 1.27 mm Pitch 2 Row Shrouded TFM-120-01-L-D-RA

Samtec TFM-120-01-L-D-RA is a shrouded straight through hole PCB header designed for demanding industrial and electronic applications, offering 40 male contacts at a 1.27 mm pitch in a 2-row configuration. This component is engineered to provide reliable and consistent connections on printed circuit boards with a robust liquid crystal polymer housing and gold-plated phosphor bronze contacts that ensure optimum conductivity and durability.

The header is rated for 3.2 A current and 250 V voltage, supporting a wide operating temperature range from -55°C to 125°C, thus suitable for harsh environments including industrial electronics, telecommunications, and instrumentation. The termination type is solder, optimized for through-hole mounting to guarantee mechanical strength.

Featuring Samtec's Tiger Eye™ multi-finger BeCu contact system, this header delivers extended life and high cycle reliability essential for long service life in high-performance electronics. The shrouded design facilitates blind mating and protects contacts during handling and assembly.

Additional special features include screw down, weld tab, and solder nail options to meet rugged application requirements. The product supports versatile orientations including vertical and right-angle to enhance design flexibility.

Applications span across industrial, laboratory, manufacturing, and communication equipment where reliable wire-to-board connections are critical. The robust construction and special options make it ideal for demanding environments requiring secure and durable electrical interconnects.

Features a 2-row configuration with male gold-plated phosphor bronze contacts. Housing is made of durable liquid crystal polymer material ensuring thermal stability. Rated for 250 V and 3.2 A current capacity for robust electrical performance.

Suitable for operating temperatures ranging from -55°C to 125°C. Designed for through-hole mounting with solder termination for secure PCB connection. Includes multi-finger BeCu contact system for high cycle and reliability applications.

Shrouded body supports blind mating and protection during assembly. Offers versatility with vertical or right-angle orientations and optional ruggedization features available. Compatible with high-reliability Tiger Eye™ contact sockets and cable assemblies.
