TE Connectivity AMPLIMITE HD-20 D-Sub Connector 9 Way Right Angle 2.74 mm Pitch Through Hole Female with 4 to 40 5747844-6

TE Connectivity model 5747844-6 AMPLIMITE HD-20 9 Way Right Angle D-Sub Connector provides a high-quality, reliable PCB mount interface used broadly in electronic assembly and industrial applications. The female connector features a 2.74 mm pitch with through hole mounting style for secure attachment to circuit boards. Constructed with a black thermoplastic 94V-0 housing and tin plated steel front shell, it sustains minimum operating temperatures down to -55°C and maximum temperatures up to 105°C.

The connector uses phosphor bronze for its contacts with a gold over nickel plating to enhance conductivity and corrosion resistance. The contacts terminate by soldering and are arranged in a right angle orientation, ideal for space-constrained layouts. This product comes with zinc-plated female screw locks sized 4 to 40 UNC for firm mechanical fastening.

The AMPLIMITE HD-20 series connectors have a footprint of 8.08 mm and are widely used in industrial power connectors, communications devices, and other electronics requiring robust D-Sub connections. The design includes tin plated brass eyelets and optional tin plated copper alloy boardlocks for additional PCB retention.

Key benefits include reliable electrical current handling up to 3 amps, a voltage rating of 1 kV for insulation integrity, and compatibility with standard AMPLIMITE HD-20 318 PCB mount series components. This connector supports high durability and longevity in harsh operating environments.

Applications include industrial controls, telecommunications, instrumentation, and other electronic equipment requiring compact, secure connector interfaces. The right angle orientation facilitates easy routing and connection of cables and PCB circuits in manufacturing settings.

Durable thermoplastic housing withstands temperatures from -55°C to 105°C. Right angle orientation suitable for space-saving PCB layouts. Contacts made of phosphor bronze with gold over nickel plating ensure corrosion resistance.

Mounting hardware includes 4 to 40 UNC screw locks for secure connections. Handles a current rating of 3A and a voltage rating of 1kV. Designed for solder termination with female connector gender. D-Sub shell size D with 8.08 mm footprint for PCB mounting.

Ideal for industrial electronics, communication equipment, and PCB interconnection applications. Compliance with AMPLIMITE HD-20 series standards ensures quality and compatibility. Explore the Electronics Components category on EnvMart for a broad range of connectors, including D-Sub types, to meet your industrial, laboratory, and manufacturing requirements.
