Abracon 32 MHz Surface Mount Crystal 8 pF Load Capacitance DFN 0.6 mm Height 2.5 mm Length 2 mm Width ABM11W
Specifications
| Country of Origin | India |
|---|---|
| Brand | Abracon |
| Height | 0.6mm |
| Length | 2.5mm |
| Model | ABM11W |
| Packaging | Reel |
| Width | 2mm |
| Mount Type | Surface |
| Series | ABM11W |
| Maximum Operating Temperature | 70°C |
| Package Type | DFN |
| Minimum Operating Temperature | -20°C |
| Standards/Approvals | RoHS, REACH |
| Standard Frequency | 32MHz |
| Load Capacitance | 8pF |
| Series Resistance | 80Ω |
Key Features
- Standard frequency of 32 MHz with ±10 ppm frequency tolerance ensures precise timing.
- Surface mount design with low profile 0.6 mm height for compact PCB designs.
- 8 pF load capacitance suited for typical oscillator circuits.
- Package dimensions of 2.5 mm length and 2 mm width for space-constrained layouts.
- Operates reliably between -20°C and 70°C operating temperature range.
- Series resistance of 80 Ω optimized for low power consumption.
- Compliance with RoHS and REACH environmental standards.
- Seam sealed construction for long-term reliability in industrial applications.
Product Description
Abracon ABM11W 32 MHz Surface Mount Crystal offers a high precision frequency source optimized for energy efficient wearable and IoT devices. Its compact DFN package with 0.6 mm profile height and dimensions of 2.5 mm length by 2 mm width makes it ideally suited for height-constrained PCB layouts and miniature electronics.
This crystal provides an 8 pF load capacitance and ±10 ppm frequency tolerance ensuring reliable and stable oscillation frequency for demanding timing applications. It features low series resistance at 80 Ω, helping minimize power consumption critical in battery-powered equipment.
The ABM11W crystal is rated for operation between -20°C and 70°C, supporting a wide range of industrial and commercial environments. RoHS and REACH compliance guarantee environmentally responsible manufacturing and use.
Typical applications include wearables, Bluetooth/Bluetooth Low Energy modules, Internet of Things (IoT) connectivity devices, ultra-low power wireless modules, near field communication (NFC) systems, and machine-to-machine (M2M) communications operating in the ISM band.
The crystal’s robust seam-sealed design ensures long term stability and reliability in wearable and wireless communication electronics requiring small form factor and minimal energy consumption.
Standard frequency of 32 MHz with ±10 ppm frequency tolerance. Low profile DFN surface mount package measuring 2.5 mm by 2 mm by 0.6 mm high. Load capacitance: 8 pF for oscillator compatibility. Series resistance of 80 Ω optimized for low power.
Operating temperature range is -20°C to 70°C. RoHS and REACH compliant for environmental safety. Seam sealed for long-term reliability. Wearables, Bluetooth, IoT, ultralow power wireless, NFC, M2M connectivity. Explore more electronics components and crystals at EnvMart for reliable industrial and commercial solutions.
Explore more products in our Crystal Unit category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The standard frequency of this crystal is 32 MHz with a frequency tolerance of ±10 ppm, ensuring precise timing for various applications.
This model has a low profile DFN surface mount package measuring 2.5 mm in length, 2 mm in width, and 0.6 mm in height, making it suitable for compact PCB designs.
The load capacitance of the ABM11W crystal is 8 pF, which is compatible with typical oscillator circuits.
The series resistance of this crystal is 80 Ω, which is optimized for low power consumption in battery-powered devices.
It operates reliably within a temperature range of -20°C to 70°C, making it suitable for various industrial and commercial environments.
Yes, it is compliant with RoHS and REACH environmental standards, ensuring responsible manufacturing and use.
This crystal features a surface mount design, which is ideal for compact electronic applications.
Typical applications include wearables, Bluetooth modules, IoT devices, ultra-low power wireless modules, NFC systems, and M2M communications in the ISM band.
The ABM11W crystal is packaged on a reel, which is common for surface mount components to facilitate automated assembly.
It features a seam-sealed construction that ensures long-term stability and reliability, particularly in wearable and wireless communication electronics.
The ±10 ppm frequency tolerance is significant as it ensures reliable and stable oscillation frequency, which is critical for timing applications.
The country of origin for this crystal is India, indicating where it was manufactured.
