HARTING har-bus HM 2 mm Pitch Type C Backplane Connector, Right Angle Female, 7 Row, 55 Way 17230552102
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 750V ac |
| Brand | HARTING |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Through Hole |
| Housing Material | Fibreglass Reinforced Thermoplastic |
| Contact Material | Copper Alloy |
| Series | har-bus HM |
| Termination Type | Press-in |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 7 |
| Pitch | 2mm |
| Contact Plating | Gold over Nickel |
| Number of Contacts | 55 |
| Contact Gender | Female |
| Connector Gender | Female |
| Backplane Connector Type | Type C |
| 5-row modules | A, B, AB, C, monoblock 47 |
Key Features
- Operates at a voltage rating of 750V ac for reliable performance.
- Current rating is 1A suitable for standard signal transmission.
- Housing made of fibreglass reinforced thermoplastic ensures durability.
- Contacts are copper alloy plated with gold over nickel for enhanced conductivity and corrosion resistance.
- Through hole mount type with press-in termination for secure installation.
- Minimum operating temperature of -55°C and maximum of 125°C suitable for harsh environments.
- Connector gender is female, with contact gender also female for proper mating.
- Complies with har-bus HM series standards, originating from Germany.
Product Description
HARTING 17230552102 har-bus HM series backplane connector is a high-quality Type C connector designed with a 2 mm pitch, featuring 7 rows and 55 contact ways arranged in a right angle female orientation. This connector supports a voltage rating of 750V ac and a current of up to 1A, providing reliable electrical connections for demanding industrial and electronic applications.
The connector housing is constructed from fibreglass reinforced thermoplastic, offering excellent mechanical strength and thermal stability, operational from -55°C up to 125°C. Its contact material is copper alloy plated with gold over nickel, enhancing electrical performance and resistance to corrosion, ideal for long-term durability in challenging environments.
Designed for through hole mounting with press-in termination, the connector ensures secure and stable connections on daughter cards and backplanes. The female connector and contact gender configuration are optimized for compatibility within the har-bus HM series.
Manufactured in Germany, this backplane connector fits into a wide range of industrial, electronic, communication, and automation equipment settings. It is a trusted choice for ensuring signal integrity and robust mechanical connection in circuit board assemblies.
2 mm pitch Type C design with 7 rows and 55 contacts for high-density interconnection. Rated for 750V ac and 1A current capacity for reliable electrical performance. Fibreglass reinforced thermoplastic housing provides strength and heat resistance.
Copper alloy contacts plated with gold over nickel improve conductivity and durability. Right angle female orientation supports flexible board mounting. Press-in termination and through hole mount type for secure installation.
Operating temperature range from -55°C to 125°C suits harsh industrial environments. Complies with har-bus HM series standards for compatibility. Explore the full range of Backplane Connectors and related industrial electronic components at EnvMart to find compatible solutions for your projects.
