Winslow 68 Way PLCC IC Socket, 1.27 mm Pitch, Surface Mount Through Hole, Straight, Phosphor Contacts, Fibreglass W9305

Winslow W9305 68 Way PLCC IC Socket is engineered for high-reliability integrated circuit mounting, offering both surface mount and through hole options suitable for a wide range of electronic assemblies. Designed to support IC packages with 1.27 mm pitch, this socket facilitates seamless connections in PCB layouts for both new and retrofit projects. Its straight orientation simplifies installation, ensuring optimal contact alignment with the corresponding PLCC device.

Featuring phosphor contacts plated with gold over nickel, the socket delivers superior conductivity and minimizes resistance, supporting up to 1A of current per contact. The robust fibreglass housing withstands mechanical stresses and temperature fluctuations, with an operating range from -55°C to 105°C, making it ideal for use in environments such as industrial controls, laboratory instrumentation, and advanced electronics manufacturing.

Designed for PLCC standard sockets, supporting 68 contacts with precise 1.27 mm pitch. Surface mount and through hole compatibility provides flexibility for PCB and module development. Gold over nickel plated contacts ensure a typical life of 500 mating cycles and reliable performance.

Straight orientation and solder termination enable straightforward PCB integration. Housing made of durable fibreglass for enhanced insulation and mechanical strength. Rated for operation at 1A per contact, suitable for a variety of digital and analog circuits.

Operates reliably from -55°C up to 105°C, suitable for demanding industrial and laboratory applications. Phosphor contacts improve electrical performance and corrosion resistance. Complies with industry standards for PLCC socket design.

Typical pins with 0.018 in (0.48 mm) diameter for secure PCB mounting.

This socket is widely used in applications such as programmable logic controllers, embedded systems, instrumentation, and prototyping platforms, enabling easy replacement and modular upgrades for PLCC ICs. Its soldered termination ensures stable connections even under repeated insertions or mechanical stress.

Choose Winslow W9305 for environments where reliable IC socketing and robust electrical connections are essential, including manufacturing automation, laboratory electronics, and complex industrial assemblies. The versatile mount options and high-quality materials make it suitable for advanced circuit design and maintenance requirements.
