Samtec ESQ Series Straight Through Hole PCB Socket 4-Contact 2 Row 2.54 mm Pitch 515V Solder ESQ-104-13-G-D

Name: Samtec ESQ Series Straight Through Hole PCB Socket 4-Contact 2 Row 2.54 mm Pitch 515V Solder ESQ-104-13-G-D
Brand: Samtec
SKU: 401331
Price: 3.53 USD
Availability: InStock



Category PCB Socket Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	515V
Brand	Samtec
Orientation	Straight
Current	5.7A
Model	ESQ-104-13-G-D
Mount Type	Through Hole
Housing Material	Black Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	ESQ
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	PCB Socket
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	4
Connector System	Board-to-Board

Key Features

Constructed with black glass filled polyester housing for durability.
Features phosphor bronze contacts plated with gold for reliability.
Rated for 5.7A current and operating voltage of 515V.
Suitable for board-to-board connector systems with solder termination.
Operates effectively between -55°C and 125°C temperature range.
Designed as part of the ESQ series elevated socket strip.
Mount type is through hole with straight orientation for PCB applications.
Lead-free solderable and RoHS compliant.

Product Description

Samtec ESQ-104-13-G-D is a PCB socket from the ESQ series designed for straight through hole mounting on printed circuit boards (PCBs). This model features a robust black glass filled polyester housing that offers high durability and mechanical strength. The socket contains 4 phosphor bronze contacts plated with gold, which ensures reliable electrical connection and resistance to corrosion.

The socket supports a current rating of 5.7 amperes per pin and is rated for an operating voltage of 515 volts, making it suitable for demanding electronic applications. It is engineered for board-to-board connector systems and terminated by soldering to provide a secure and stable connection. The socket has two rows of contacts arranged with a 2.54 mm pitch, ensuring compatibility with standard PCB layouts.

Operating temperature ranges from -55°C to 125°C enable use in various industrial and commercial environments, including electronic manufacturing, testing equipment, and instrumentation. The Samtec ESQ series sockets are RoHS compliant and lead-free solderable, supporting environmentally responsible manufacturing and compliance standards.

This elevated socket strip design enhances accessibility and usability for multiple circuit board applications. It is suitable for industrial, laboratory, manufacturing, and electronic assembly scenarios where reliable socket performance and durability are critical.

Black glass filled polyester housing for mechanical strength. Phosphor bronze contact material plated with gold. High current rating of 5.7A per contact. Solder termination with through hole mount type. Compatible with board-to-board connector systems.

Wide operating temperature range from -55°C to 125°C. 2.54 mm row pitch with 4 contacts arranged in 2 rows. RoHS compliant and lead-free solderable for environmental safety. Explore the wide range of PCB Sockets and connectors at EnvMart to find suitable components for your electronic and industrial projects.
