Phoenix Contact SPT-SMD 1.5/2-V-5.0 R24 Series PCB Terminal Block, 2 Contacts, 5 mm Pitch, Liquid Crystal Polymer 1824307

Phoenix Contact SPT-SMD 1.5/2-V-5.0 R24 Series PCB Terminal Block, model 1824307, is engineered for secure and efficient PCB connectivity applications. This terminal block features a 5 mm pitch and accommodates 2 contacts in a single row, providing a compact solution for board-level interconnections.

Suitable for PCB mounting with a 5 mm pitch design. Features a spring actuation lever for tool-free, reliable wire connection. Accommodates solid or stranded conductors up to 1.5 mm². Constructed with liquid crystal polymer housing for high durability.

Offers 2 contacts in a single row with straight orientation. Allows quick push-in spring technology for fast installation. Depth of 13.6 mm, length of 9 mm, and width of 7.7 mm. Supports wire sizes from 0.2 mm² to 1.5 mm² (AWG 24 - 16).

Black color for easy identification in assemblies. Complies with tape-on-reel packaging standards for automated assembly.

This terminal block utilizes a combination of spring cage and direct push-in technology, ensuring tool-free connection and reliable electrical contact. The spring actuation lever enables easy engagement and disconnection of wires, saving installation time and minimizing maintenance requirements.

Manufactured with liquid crystal polymer material, the housing exhibits excellent mechanical strength, thermal stability, and chemical resistance, suited for demanding environments in electronics manufacturing, power distribution, and control panels.

The product supports wire sizes from 0.2 mm² to 1.5 mm², including AWG 24 to AWG 16, catering to a wide range of conductor specifications. Its straight orientation and compact dimensions (13.6 mm depth, 9 mm length, 7.7 mm width) make it ideal for dense PCB layouts.

With tape-on-reel packaging according to IEC 60283-3, the SPT-SMD series ensures compatibility with automated assembly lines and reflow processes. Common industrial applications include electronic circuit assembly, power supplies, control and signal interfaces, automation equipment, and laboratory instrumentation.
