| Country of Origin | Japan |
|---|---|
| Brand | Murata |
| Height | 1.83mm |
| Length | 2.62mm |
| Model | LQW2UAS4R7J00L |
| Depth | 2.45mm |
| Packaging | Paper Tape |
| Series | LQW |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Non-Magnetic Core |
| Inductance | 4.7μH |
| Standards/Approvals | RoHS |
| Package/Case | 2520 |
| Maximum DC Current | 260mA |
| Pin Count | 2 |
| Maximum DC Resistance | 4Ω |
| Inductance Tolerance | ±5 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 60MHz |
| Minimum Quality Factor | 20 |
| Inductor Construction | Wirewound |
Murata LQW2UAS4R7J00L is an unshielded wirewound surface mount inductor featuring a non-magnetic core construction and a 4.7μH inductance with ±5 % tolerance. This component supports a maximum DC current of 260mA and operates efficiently within a temperature range from -55°C to 125°C.
Designed in a compact 2520 package, the inductor is ideal for high-frequency applications up to 60MHz, benefiting from a minimum quality factor of 20. Its low DC resistance of 4Ω ensures minimal power loss, making it suitable for RF circuits and antenna matching tasks where signal sensitivity is critical.
The moulded wirewound construction enhances mechanical strength and reliability, while the solder termination style allows for straightforward surface mount technology (SMT) assembly processes. Fully RoHS compliant, this inductor meets environmental and safety standards required for modern electronic manufacturing.
Murata's LQW series inductors are well-suited for industrial and commercial electronics, including consumer electronics, telecommunications equipment, and automotive electronics where stable RF performance and current handling are required.
Non-magnetic core construction minimizes interference and magnetic coupling. High-quality wirewound technology provides stable inductance with low resistance. Compact 2520 package size optimizes PCB space. Wide operating temperature range ensures reliability in diverse environments.
High self-resonant frequency supports demanding high-frequency applications. Low DC resistance reduces power loss, increasing overall efficiency. Solder termination style facilitates reliable electrical connections. RoHS compliant design aligns with environmental regulations.
Perfect for choke circuits and antenna matching uses. Manufactured in Japan, ensuring quality and precision. Explore the extensive range of electronic components and Surface Mount Inductors at EnvMart for your industrial, commercial, and laboratory needs.
