Samtec Right Angle Through Hole PCB Header, 8 Contacts, 2.54 mm Pitch, 2 Row, Shrouded, 675V IPL1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 675V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 3.8A |
| Model | IPL1 |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | IPL1 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Designed for wire-to-board applications with robust solder termination.
- Features right angle through hole mounting for improved PCB space management.
- 8 contacts arranged in 2 rows support reliable signal transmission.
- Liquid Crystal Polymer housing offers thermal stability and durability.
- Gold phosphor bronze contacts ensure superior electrical conductivity.
- Operates reliably in temperatures from -55°C to 125°C.
- Rated for up to 3.8A and 675V high voltage operation.
- Shrouded header prevents misalignment during mating.
Product Description
Samtec IPL1-104-01-L-D-RE1-K Right Angle Through Hole PCB Header offers a sturdy and precise solution for wire-to-board connections in modern electronic assemblies. Featuring a shrouded design with 8 male pins in 2 rows, this header enables secure and reliable mating for circuit boards that require robust signal or power transmission.
With a pitch of 2.54 mm, the connector fits standard PCB layouts and allows for versatile integration across industrial and commercial electronics. Its right angle orientation and through-hole mounting facilitate efficient board space utilization and easy soldering, making it suitable for both prototyping and production environments.
The housing is made from Liquid Crystal Polymer, delivering high mechanical strength and excellent thermal stability, rated for operation between -55°C and 125°C. Phosphor bronze contacts plated with gold ensure maximum electrical performance, featuring low contact resistance and long-term reliability even in demanding applications.
This header is shrouded to protect the contacts and guarantee correct alignment during mating, reducing assembly errors and improving operational integrity. With a maximum voltage rating of 675V and current handling up to 3.8A, it is ideal for signal and power distribution in instrumentation, control boards, sensors, and embedded systems.
Engineered for secure wire-to-board connections in PCB designs. Through-hole mounting and right angle geometry support compact layouts. Shrouded header prevents mis-insertion and protects pin integrity. Gold-plated contacts offer superior conductivity and corrosion resistance.
Durable LCP housing withstands thermal and mechanical stress environments. Supports up to 8 contacts in a reliable double-row configuration. Wide operating temperature range from -55°C to 125°C, suited for industrial use.
Rated for 3.8A current and 675V voltage for advanced circuit designs. Ideal for manufacturing, IoT, automation, and embedded electronics.
This connector is widely applicable in electronics manufacturing, industrial automation, automotive, sensor interfacing, and embedded hardware where secure and high-performance PCB connectivity is essential.
Browse Samtec PCB Header products and related connectors in the Electronics Components category on EnvMart.
