Artesyn / Advanced Energy AYA Series DC/DC Converter 15V DC Output, 100 mA, 4.5 - 10V DC Input, 3W, Through Hole AYA01CC05-L
Specifications
| Country of Origin | India |
|---|---|
| Voltage | Converters / DC-DC Converters Artesyn / Advanced Energy AYA DC/DC Converter, 15V |
| Brand | Artesyn / Advanced Energy |
| Efficiency | 85% |
| Length | 14mm |
| Model | AYA01CC05-L |
| Depth | 8mm |
| Width | 14mm |
| Mount Type | Through Hole |
| Series | AYA |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| MTBF | 3500000h |
| Number of outputs | 2 |
| Maximum Output Power | 3W |
| Maximum Input Voltage | 10V dc |
| Minimum Input Voltage | 4.5V |
| Number of Pins | 7 |
| Output Voltage 1 | 15V dc |
| Output Current 1 | 100mA |
| Isolation Voltage | 1.5kV dc |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
| Output Voltage 2 | -15V dc |
| Wide 2 | 1 Input Range |
Key Features
- Regulated 15V DC output and up to 100 mA output current.
- Supports dual input voltage range from 4.5V to 10V DC.
- Maximum output power rating of 3W for demanding applications.
- Ultra compact DIP package for efficient board space usage.
- Operates safely between -40°C to 85°C ambient temperature.
- Through hole mounting for robust PCB integration.
- Provides I/O isolation up to 1.5kV DC for enhanced circuit safety.
- Ideal for telecommunication, industrial automation, and battery-operated devices.
Product Description
The Artesyn / Advanced Energy AYA01CC05-L belongs to the AYA Series of isolated DC/DC converters, delivering a regulated 15V DC output at up to 100 mA from a dual input voltage range of 4.5V to 10V DC. The converter offers a maximum power output of 3W, making it well-suited for powering sensitive electronic circuits and peripherals with precision and reliability.
This model is housed in a compact dual-in-line (DIP) package measuring only 14 x 14 x 8 mm, with a robust through-hole mounting configuration, making it ideal for applications requiring stable integration and space efficiency on the PCB. The device operates efficiently across a wide ambient temperature range from -40°C to 85°C, ensuring reliable performance in harsh industrial environments and variable climate conditions.
The AYA01CC05-L features an I/O isolation voltage of 1.5kV DC, protecting both the load and upstream components from voltage surges and system faults. Its high conversion efficiency, up to 85%, minimizes energy loss and reduces heat generation, benefiting end-users relying on compact and energy-sensitive systems such as mobile and battery-powered devices.
With support for remote ON/OFF functionality and continuous hiccup mode protection against output short circuits, the converter safeguards connected loads while maintaining operational integrity. It is equipped with seven pins for easy connectivity and offers dual output voltages (+15V and -15V), broadening its applicability for circuits requiring both polarities.
Designed for use in data communication, telecommunication, industrial automation, and computer peripherals, this DC/DC converter is a high-reliability power solution for engineers seeking robust performance, compact size, and versatile design integration.
Regulated 15V and -15V DC outputs provide versatility for bipolar power requirements. Wide 2:1 input voltage range (4.5V - 10V DC) ensures compatibility with varied supply sources. 3500000 hours MTBF highlights its reliability in continuous operation settings.
Supports continuous overcurrent protection and remote control via ON/OFF pin. Certified to EN 55022 Class A and FCC Level A for electromagnetic compatibility. DIP package and through-hole orientation simplifies assembly and maintenance in industrial applications.
Suitable for industrial, telecom, laboratory, and mobile battery-powered systems. Explore more Artesyn / Advanced Energy DC-DC Converters in the EnvMart catalogue for advanced power solutions tailored to technical and industrial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a regulated output voltage of 15V DC with a maximum output current of 100 mA.
The AYA01CC05-L supports a dual input voltage range from 4.5V to 10V DC.
It has a maximum output power rating of 3W, suitable for various applications.
The converter is housed in a compact DIP package measuring 14mm in length, 14mm in width, and 8mm in depth.
It operates efficiently between -40°C and 85°C, making it suitable for harsh environments.
The AYA01CC05-L utilizes a through-hole mounting configuration for robust PCB integration.
It features an I/O isolation voltage of 1.5kV DC, enhancing circuit safety.
This model has two outputs: +15V and -15V DC, allowing for bipolar power requirements.
The AYA01CC05-L has an efficiency rating of up to 85%, minimizing energy loss.
It has a Mean Time Between Failures (MTBF) of 3,500,000 hours, indicating its reliability in continuous operation.
This model is designed for use in data communication, telecommunication, industrial automation, and battery-operated devices.
It supports remote ON/OFF functionality and includes continuous hiccup mode protection against output short circuits.
