Artesyn / Advanced Energy ATA DC/DC Converter, 12V, -12 V Output, 250 mA, 75V DC Input, 18V Minimum Input, 6 W ATA01BB36-L

Free Delivery in India | Lowest Global Shipping Charges

Artesyn / Advanced Energy ATA DC/DC Converter, 12V, -12 V Output, 250 mA, 75V DC Input, 18V Minimum Input, 6 W ATA01BB36-L

Name: Artesyn / Advanced Energy ATA DC/DC Converter, 12V, -12 V Output, 250 mA, 75V DC Input, 18V Minimum Input, 6 W ATA01BB36-L
Brand: Artesyn / Advanced Energy
SKU: 318651
Price: 441.12 USD
Availability: InStock



Category DC/DC Converter Brand Artesyn / Advanced Energy Condition New

Specifications

Country of Origin	Taiwan
Voltage	Converters / DC-DC Converters Artesyn / Advanced Energy ATA DC/DC Converter, 12V
Brand	Artesyn / Advanced Energy
Efficiency	85%
Length	23.8mm
Model	ATA01BB36-L
Depth	8mm
Width	13.7mm
Mount Type	Through Hole
Series	ATA
Maximum Operating Temperature	90°C
Package Type	DIP
Minimum Operating Temperature	-40°C
Number of outputs	2
Maximum Output Power	6W
Maximum Input Voltage	75V dc
Minimum Input Voltage	18V
Output Voltage 1	12, -12V
Output Current 1	250mA
Isolation Voltage	1.5kV dc
Ultra-wide 4	1 input range

Key Features

Supports ultra-wide input voltage range from 18V to 75V DC.
Features a compact DIP package with through-hole mounting for easy PCB integration.
High efficiency of 85% ensures low energy loss during operation.
Offers 1.5 kV DC isolation voltage for safety and noise reduction.
Operates reliably within a temperature range of -40°C to 90°C maximum.
Mini dual-in-line package measuring 23.8 mm x 13.7 mm x 8 mm.
Designed for diverse low power applications including industrial automation and telecommunications.
Provides remote On/Off control capability for flexible use.

Product Description

Artesyn / Advanced Energy ATA01BB36-L DC/DC Converter is a high-quality isolated power module delivering dual outputs of +12 V and -12 V at an output current of 250 mA. With a maximum power output of 6 W and an ultra-wide input voltage range from 18V up to 75V DC, this converter is ideal for applications in industrial automation, data communication, telecommunication, and mobile battery-powered systems.

The device features a robust DIP package designed for through-hole mounting, measuring 23.8 mm in length, 13.7 mm in width, and 8 mm in depth, suitable for compact PCB layouts. It offers an isolation voltage of 1.5 kV DC ensuring safety and electrical noise isolation integral to sensitive electronic applications.

With an efficiency rating of up to 85%, the ATA01BB36-L minimizes energy loss, enhancing reliability and reducing heat generation. It operates within a broad temperature range of -40°C to 90°C, making it suitable for harsh environmental conditions.

The converter supports remote On/Off control, enabling integration flexibility in automated and controlled environments. Featuring a mini dual-in-line package, it simplifies installation and mechanical integration.

This DC/DC converter series is backed by a three-year warranty, reflecting Artesyn / Advanced Energy's commitment to durable and dependable power solutions. Supports ultra-wide 4:1 input voltage range from 18V to 75V DC.

Provides dual outputs of +12 V and -12 V at 250 mA output current. Compact DIP package with through-hole mount design. Isolation voltage of 1500 V DC ensures operational safety. High efficiency of 85% reduces power loss and heat generation.

Operating temperature range from -40°C to 90°C maximizes versatility. Ideal for industrial automation, telecommunications, and battery-powered systems. Explore more high-quality DC/DC Converters and power solutions at EnvMart for your industrial and electronics design needs.
