Radiall RP-SMP Series Coaxial Connector Panel Mount Female SMP, 50 Ω, Straight Body Solder R222252301W
Specifications
| Country of Origin | France |
|---|---|
| Size | Standard |
| Brand | Radiall |
| Orientation | Straight |
| Model | R222252301W |
| Mount Type | Panel Mount |
| Operating Frequency | 40GHz |
| Contact Material | Beryllium Copper Alloy |
| Series | RP-SMP |
| Termination Type | Solder |
| Maximum Operating Temperature | 165°C |
| Cable Type | KS 1, RG405 |
| Minimum Operating Temperature | -65°C |
| Polarity | Reverse |
| Impedance | 50Ω |
| Contact Plating | Gold over Nickel |
| Contact Gender | Male |
| Connector Gender | Female |
| Coaxial Connector Type | SMP |
| Body Plating | Gold over Nickel |
| Radiall, Plug Panel Mount, 50Ω, Solder Termination, Straight BodyBrand | Radiall |
Key Features
- Ultra-miniature RP-SMP series coaxial connector suitable for high-density packaging applications.
- Panel mount design enhances installation flexibility for RF systems.
- Female SMP interface and straight body configuration allow precise signal transmission.
- Impedance of 50 ohms optimizes performance for high-frequency applications up to 40 GHz.
- Solder termination ensures secure electrical contact and reliability.
- Gold over nickel plated body provides corrosion resistance and improved conductivity.
- Reverse polarity configuration for specialized RF circuit needs.
- Operates reliably over a temperature range from -65°C to 165°C.
Product Description
Radiall R222252301W is an RP-SMP series panel mount coaxial connector designed to provide robust RF connectivity in high-density applications. The connector features a female SMP interface with a straight body configuration, offering a compact form factor for environments where space-saving and performance are critical.
This model is engineered specifically for panel mounting, simplifying integration into RF enclosures, test equipment, communication devices, and phased array antenna systems. With an impedance rating of 50 Ω, the connector offers optimal signal integrity and low-loss performance across frequencies up to 40 GHz. Its gold over nickel-plated body ensures excellent corrosion resistance and reliable electrical conductivity, making it suitable for mission-critical applications including airborne, shipborne, and ground radar systems.
Solder termination provides a stable and durable connection, supporting secure installation and minimizing signal discontinuities. The reverse polarity configuration caters to specialized RF requirements, preventing incorrect mating. The connector is constructed using beryllium copper alloy for contacts, ensuring both mechanical strength and electrical reliability in demanding environments.
This RP-SMP series connector meets MIL STD 348 and DESC 94007/94008 specifications, providing ultra-miniature interface capabilities ideal for blindmate operations. It tolerates axial and radial misalignments and delivers outstanding vibration and shock performance.
Typical applications include phased array antennas, satellite communication systems, radar, and communication equipment requiring reliable RF connections with minimal footprint. The wide operating temperature range of -65°C to 165°C and frequency up to 40 GHz make it suitable for both industrial and laboratory use as well as commercial RF network deployments.
Explore EnvMart’s extensive selection of Radiall Coaxial Connectors and discover more high-performance solutions for RF and microwave connectivity in demanding electronic applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Radiall RP-SMP series connector operates at a maximum frequency of 40 GHz, ensuring optimal signal integrity for high-frequency applications.
This connector has an impedance rating of 50 ohms, which is ideal for minimizing signal loss in RF applications.
It features a solder termination type, which provides a stable and durable electrical connection.
This model operates reliably over a temperature range from -65°C to 165°C, making it suitable for various environments.
The contacts are made from beryllium copper alloy, and the body is plated with gold over nickel for enhanced conductivity and corrosion resistance.
This connector is designed for panel mounting, which allows for flexible installation in RF systems.
The connector has a female SMP interface, allowing it to mate with compatible male connectors.
Yes, this connector features a reverse polarity configuration, which helps prevent incorrect mating in specialized RF applications.
Typical applications include phased array antennas, satellite communication systems, and radar, where reliable RF connections are required.
This model is classified as a standard size connector, suitable for high-density packaging applications.
It meets MIL STD 348 and DESC 94007/94008 specifications, making it suitable for mission-critical RF connectivity.
This connector is compatible with KS 1 and RG405 cable types, ensuring versatility in various RF applications.
