Eaton xPole PXL Miniature Circuit Breaker, 3-Pole, 10A, Type D, 400V AC, 48V DC, 10kA, DIN Rail, IP20 236461 PXL-D10/3
Specifications
| Country of Origin | Austria |
|---|---|
| Range | xPole |
| Brand | Eaton |
| Height | 52.5mm |
| Model | 236461 PXL-D10/3 |
| Depth | 60mm |
| IP Rating | IP20 |
| Width | 80mm |
| Mount Type | DIN Rail |
| Current Rating | 10A |
| Series | PXL |
| Breaking Capacity | 10kA |
| Number of Poles | 3 |
| Standards/Approvals | EN 60898, IEC |
| Rated AC Voltage | 400V ac |
| Rated DC Voltage | 48V dc |
| Tripping Characteristics | Type D |
| Tripping Mechanism | Electromagnetic |
| Reset Actuator Type | Toggle Switch |
| Break Time | Instantaneous |
Key Features
- Designed for industrial and commercial protection against overloads and short circuits.
- Supports both AC (400V) and DC (48V) circuit protection.
- Features a D-curve tripping characteristic suitable for high inrush applications.
- High breaking capacity of 10kA ensures safety in demanding installations.
- Built for DIN rail mounting with quick-fit action and 3 locking positions.
- Finger-proof and back-of-hand-proof IP20 enclosure for enhanced safety.
- Double terminal configuration for secure bus bar and cable connections.
- Electromagnetic tripping mechanism for reliable performance.
Product Description
The Eaton 236461 PXL-D10/3 Miniature Circuit Breaker offers robust, reliable protection for electrical circuits in demanding industrial, laboratory, and commercial environments. Designed to safeguard electrical installations from overload and short-circuit conditions, this 3-pole MCB features a D-curve tripping characteristic, making it ideal for circuits with high inrush currents such as motors and transformers.
This MCB operates at both 400V AC and 48V DC, providing versatile protection across a wide range of applications. Its high breaking capacity of 10kA ensures that electrical faults are managed safely and efficiently, reducing risk and downtime. The device can be easily installed on standard DIN rails thanks to its quick-fit action mechanism that offers three locking positions and free selection of rail arrangement.
Safety is paramount with the Eaton xPole PXL series. The circuit breaker is housed within an IP20-rated enclosure, offering both finger-proof and back-of-hand-proof protection to prevent accidental contact with live terminals. It features double terminal lift/jaw top and bottom for flexible and secure bus bar or cable connections. The electromagnetic tripping mechanism delivers fast and accurate fault response, and the toggle switch actuator allows for convenient reset and operation.
With standards compliance to EN 60898 and IEC certifications, the 236461 PXL-D10/3 is suitable for industrial power distribution, laboratory equipment protection, commercial facility installations, and other applications requiring high selectivity as a pre-fuse with low passband energy. Its compact size (80mm width, 52.5mm height, 60mm depth) makes it ideal for modular panels and space-constrained environments.
This circuit breaker is used in machine tool control cabinets, HVAC panels, water treatment systems, lighting installations, and other critical applications where electrical protection and operational reliability are essential.
EnvMart offers a comprehensive range of Eaton MCBs and electrical protection devices. Browse our Miniature Circuit Breaker category for more options and industry-leading solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The breaking capacity of this circuit breaker is 10kA, ensuring safe management of electrical faults.
It operates at a rated AC voltage of 400V and a rated DC voltage of 48V.
This model features a D-curve tripping characteristic, suitable for high inrush applications such as motors and transformers.
It is designed for DIN rail mounting and features a quick-fit action with three locking positions for easy installation.
The dimensions are 80mm in width, 52.5mm in height, and 60mm in depth.
It utilizes an electromagnetic tripping mechanism for reliable performance and fast fault response.
The circuit breaker has an IP20 rating, providing finger-proof and back-of-hand-proof protection.
It complies with EN 60898 and IEC standards, ensuring reliability in various applications.
It is suitable for industrial power distribution, laboratory equipment protection, and commercial facility installations.
The current rating of this circuit breaker is 10A.
It features a toggle switch as the reset actuator type for convenient operation.
The country of origin for this product is Austria.
