Weidmüller LSF Series PCB Terminal Block, 5-Contact, 5 mm Pitch, 1 Row, Push-in Connection, 500V, 17.5A, Copper 1473800000
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 500V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | Right Angle |
| Current | 17.5A |
| Depth | 14.75mm |
| Width | 24.2mm |
| Housing Material | Copper |
| Series | LSF |
| Number of Rows | 1 |
| Pitch | 5mm |
| Standards/Approvals | RoHS, UL |
| Number of Contacts | 5 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Push-in |
Key Features
- This terminal block features push-in wire connection for quick and tool-free installation.
- It has 5 contacts arranged in a single row with a 5 mm pitch for compact PCB mounting.
- The copper housing provides excellent conductivity and durability.
- Rated for 17.5 amperes current and withstands voltages up to 500 volts.
- The terminal block is oriented at a right angle to the PCB for space-efficient design.
- Suitable for wires from 0.2 mm² to 1.5 mm² or AWG 28 to 14.
- Complies with RoHS and UL standards ensuring safety and environmental compliance.
- Color coded push buttons allow easy distinction of potentials and clamping points.
Product Description
Weidmüller 1473800000 PCB Terminal Block is a high-quality component designed for use in electronic equipment and automation systems, supporting currents up to 17.5 amperes and voltages up to 500 volts. This 5-contact, single row terminal block with a 5 mm pitch features a push-in connection system that allows fast, secure, and tool-free wiring of solid wires or wires with end ferrules, optimizing assembly efficiency.
The copper housing ensures excellent electrical conductivity and mechanical robustness. Its right-angle orientation helps optimize PCB space usage, suitable for compact design requirements. Compliance with RoHS and UL standards guarantees the product meets strict environmental and safety criteria.
The push-in connection mechanism uses colored push buttons to mark potentials and clamping points clearly, enhancing usability during assembly and maintenance. The terminal block is capable of fully automated placement in reflow soldering processes, making it ideal for modern manufacturing workflows.
Typical use cases include industrial automation, control panels, instrumentation, and other electrical assembly tasks requiring reliable PCB connectivity. Its compact size and robust performance also support multi-layer PCB designs with up to 72 poles.
This terminal block delivers efficient and reliable electrical interconnection on printed circuit boards. Supports automatic SMT assembly with reflow soldering compatibility. Push-in connection ensures user-friendly and secure wire fixing without tools.
Copper housing provides durability and enhances performance. Complies with major safety and environmental standards (RoHS, UL). Compact form factor enables space-saving PCB layouts. Clear color marking facilitates wiring identification and maintenance.
Suitable for current ratings up to 17.5 A and voltage up to 500 V. Wire size compatibility from 0.2 mm² to 1.5 mm² offers versatility. Explore the full range of Weidmüller Pluggable Terminal Blocks at EnvMart for advanced electronic component solutions.
