Norcomp SDF 15-Way Right Angle Surface Mount D-Sub Connector, 2.74 mm Pitch, 1000V, 5A, Female, Board Lock SDF-R15-213L461
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 1000V |
| Brand | Norcomp |
| Orientation | Right Angle |
| Current | 5A |
| Model | SDF-R15-213L461 |
| Mount Type | Surface |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | SDF |
| Mounting Hardware | 4-40 Board Lock |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -25°C |
| Pitch | 2.74mm |
| Contact Plating | Gold |
| Number of Contacts | 15 |
| Contact Gender | Female |
| Connector Gender | Female |
| Connector Type D | Standard |
Key Features
- Features a 15-contact female standard D-sub configuration.
- Right angle design for surface mount installations on PCBs.
- 2.74 mm pitch ensures compatibility with standard board layouts.
- Rated for 1000V maximum voltage and 5A current per contact.
- Polybutylene Terephthalate (PBT) housing offers durability and insulation performance.
- Gold-plated brass contacts provide excellent conductivity and corrosion resistance.
- Includes secure 4-40 board lock hardware for firm attachment.
- Operating temperature range from -25°C to 85°C.
Product Description
The Norcomp SDF-R15-213L461 is a precision-engineered D-sub connector designed for applications requiring a robust, surface mount solution. With 15 female contacts arranged in a standard right angle configuration, this connector is ideal for integration onto PCBs within electronic and electrical devices.
The 2.74 mm pitch between contacts supports easy layout and assembly on boards and adheres to industry standards for D-sub connector footprints. This model delivers high electrical performance, featuring a voltage rating up to 1000V and a maximum current of 5A per contact, providing reliable connectivity for power and signal transmission in critical circuits.
Its enclosure is crafted from Polybutylene Terephthalate (PBT), ensuring superior strength and insulating properties. The connector incorporates gold-plated brass contacts for optimal conductivity and corrosion resistance, further enhancing performance in varying environmental conditions. The included 4-40 board lock mounting hardware guarantees stable retention during installation and operation, minimizing risk of connector movement or failure.
Built for high reliability, this connector operates effectively across a wide temperature range, from -25°C to 85°C, making it suitable for industrial, computing, instrumentation, and commercial electronics use. Applications include PCB assembly for industrial control systems, servers, computers, and communication equipment where secure, multi-pin connection is required.
The Norcomp SDF-R15-213L461 leverages the SDF series construction, offering IP67 rating for protection against dust and moisture. Insulation resistance is rated at 5 Gohms, providing assurance in electrically demanding environments. The connector housing’s flame retardance of UL 94V-0 (230°C process temp) supports safety and compliance needs.
Select Norcomp connectors for your next PCB project to benefit from advanced engineering, trusted performance, and compatibility with industry connection standards. Explore more D-Sub Connector solutions in the Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Norcomp SDF-R15-213L461 is rated for a maximum voltage of 1000V.
This model supports a maximum current of 5A per contact.
The contact pitch for this connector is 2.74 mm, ensuring compatibility with standard board layouts.
It features a surface mount design, suitable for installation on printed circuit boards (PCBs).
The housing is made from Polybutylene Terephthalate (PBT), and the contacts are made of brass with gold plating for improved conductivity.
The operating temperature range is from -25°C to 85°C, making it suitable for various environments.
This model has 15 female contacts arranged in a standard D-sub configuration.
It includes 4-40 board lock mounting hardware for secure attachment during installation.
Yes, it has an IP67 rating for protection against dust and moisture.
It is suitable for PCB assembly in industrial control systems, servers, computers, and communication equipment.
The Norcomp SDF-R15-213L461 is manufactured in Taiwan.
This D-sub connector features a female gender configuration.
