Wurth Elektronik Pluggable Terminal Block 2-Contact 5 mm Pitch 1 Row Horizontal Male Screw Connection 691369700002B
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 2.5kV |
| Brand | Wurth Elektronik |
| Colour | Grey |
| Orientation | Horizontal |
| Current | 16A |
| Length | 11.5mm |
| Model | 691369700002B |
| Depth | 26.5mm |
| Width | 14.6mm |
| Housing Material | Polyamide 66 |
| Series | 369B |
| Number of Rows | 1 |
| Pitch | 5mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 2 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.081mm² |
| Maximum Wire Size mm² | 3.31mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Screw |
Key Features
- Provides 2-contact pluggable terminal block connection for PCB mounting.
- Features a 5 mm pitch between contacts for standard compatibility.
- Utilizes screw connection for secure wire fixing and easy installation.
- Handles a maximum current of 16A and voltage up to 2.5 kV for robust applications.
- Supports wire sizes from 0.081 mm² (28 AWG) up to 3.31 mm² (12 AWG).
- Constructed with durable polyamide 66 housing for thermal and mechanical stability.
- Horizontal orientation and male gender configuration optimize space efficiency.
- Complies with RoHS standards for safe electronic assembly.
Product Description
Wurth Elektronik 691369700002B Pluggable Terminal Block is engineered for high-performance PCB applications, ensuring reliable electrical connections with a robust horizontal male screw connection mechanism. Its compact form factor incorporates a durable polyamide 66 housing, ideal for demanding environments.
This terminal block features 2 contacts with a 5 mm pitch, compatible with a wide range of wire sizes from 0.081 mm² (28 AWG) up to 3.31 mm² (12 AWG). The screw connection method not only guarantees secure cable fixing but also facilitates user-friendly installation in industrial, commercial, and laboratory settings.
Designed to handle a maximum current of 16A and voltage up to 2.5 kV, this component is suitable for applications requiring robust electrical protection and insulation. The horizontal orientation and male gender connector help optimize PCB layout and space utilization, making it popular among electronics manufacturers and engineers.
Polyamide 66 construction ensures long-term mechanical and thermal stability, even under challenging operational conditions. Grey coloration adds clarity for identification during PCB assembly or electrical maintenance.
RoHS compliance is assured, supporting safe, green manufacturing practices. This terminal block is suitable for control panels, industrial automation, power distribution, HVAC systems, and custom PCB designs.
With precise measurements (length 11.5 mm, width 14.6 mm, depth 26.5 mm), this terminal block can be integrated into compact or space-constrained assemblies. Provides 2-contact pluggable terminal block connection for PCB mounting.
Features a 5 mm pitch between contacts for standard compatibility. Utilizes screw connection for secure wire fixing and easy installation. Handles a maximum current of 16A and voltage up to 2.5 kV for robust applications.
Supports wire sizes from 0.081 mm² (28 AWG) up to 3.31 mm² (12 AWG). Constructed with durable polyamide 66 housing for thermal and mechanical stability. Horizontal orientation and male gender configuration optimize space efficiency.
Complies with RoHS standards for safe electronic assembly. Explore more Wurth Elektronik terminal blocks in the Terminal Blocks category on EnvMart to find compatible options for your projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It can handle a maximum current of 16A and a voltage of up to 2.5 kV, suitable for robust applications.
This terminal block supports wire sizes ranging from 0.081 mm² (28 AWG) to 3.31 mm² (12 AWG).
The pitch between the contacts is 5 mm, which ensures standard compatibility with various applications.
It features a horizontal orientation and a male gender configuration, optimizing space efficiency on PCBs.
The housing is constructed from polyamide 66, providing thermal and mechanical stability.
The dimensions are 11.5 mm in length, 14.6 mm in width, and 26.5 mm in depth.
It utilizes a screw connection method for secure wire fixing and easy installation.
Yes, it complies with RoHS standards, supporting safe electronic assembly.
It is suitable for control panels, industrial automation, power distribution, HVAC systems, and custom PCB designs.
This model is part of the 369B series of terminal blocks.
The country of origin for this terminal block is China.
The terminal block is grey in color, which aids in identification during assembly or maintenance.
