Weidmüller BL Series Pluggable Terminal Block, 16 Contacts, 5.08 mm Pitch, 1 Row, 400V, 20A, Copper Alloy Housing 1943950000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 400V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | Right Angle |
| Current | 20A |
| Length | 92.2mm |
| Depth | 16mm |
| Width | 20.1mm |
| Housing Material | Copper Alloy |
| Series | BL |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 16 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 4mm² |
| Minimum Wire Size AWG | 26AWG |
| Maximum Wire Size AWG | 12AWG |
| Wire Connection Method | Screw |
| Lock and release-lever | tool-less locking and gentle releasing of the connector reduces the mechanical stress on the solder joints |
Key Features
- Provides a reliable pluggable connection for electrical and signal wiring systems.
- Features a 16-contact, single-row configuration for compact panel installations.
- Supports up to 20A current and 400V voltage ratings suitable for industrial environments.
- Copper alloy housing ensures durability and stable conductivity.
- Screw connection with integrated wire guard prevents under-insertion and improves safety.
- Accommodates wire sizes from 0.2 mm² (26 AWG) up to 4 mm² (12 AWG).
- Tool-less lock and gentle release lever reduces stress on solder joints and simplifies installation.
- Right angle orientation facilitates space-saving mounting and efficient cable routing.
Product Description
The Weidmüller BL Series Pluggable Terminal Block model 1943950000 is engineered for robust electrical connection solutions in demanding industrial and automation control environments. Designed for easy and reliable pluggable wiring, this terminal block features a 16-contact female connector in a single-row format, offering efficient installation in panel and PCB applications.
With a precise 5.08 mm pitch, this product accommodates a wide range of wire sizes, from 0.2 mm² (26 AWG) to 4 mm² (12 AWG), making it suitable for diverse industrial wiring standards. The copper alloy housing provides enhanced electrical conductivity and long-term durability, while its black color seamlessly matches professional equipment aesthetics.
The terminal block supports a maximum current of 20A and a voltage up to 400V, ensuring it meets heavy-duty power and signal distribution needs across manufacturing, process control, HVAC, and automation installations. The integrated screw wire connection method and wire guard feature protect against accidental under-insertion, increasing user safety and contact reliability.
Installation is made efficient with a tool-less locking and gentle release lever, which minimizes mechanical stress on solder joints and enables repeated pluggable cycles without degradation. The right-angle orientation further optimizes cable management in confined spaces, allowing technicians to route wires smoothly within cabinets or equipment enclosures.
Additional functional enhancements include terminal points delivered wire-ready, plus/minus screw head compatibility for power tools, and a folded steel clamping yoke that compensates for temperature fluctuations and wire expansion. The product is RoHS compliant and manufactured in Germany, ensuring adherence to international environmental and quality standards.
Dimensions are compact at 92.2 mm length, 20.1 mm width, and 16 mm depth, making it ideal for tight panel layouts. The product is part of the Weidmüller BL Series, renowned for secure pluggable terminal technology, and is commonly used in industrial, automation, power distribution, and control panel applications.
Explore more Weidmüller Terminal Blocks and electronic connection solutions in the Electronics Components category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This terminal block supports a maximum current of 20A.
It is rated for a maximum voltage of 400V.
The contact pitch is 5.08 mm.
It features 16 contacts in a single-row configuration.
It accommodates wire sizes from 0.2 mm² (26 AWG) to 4 mm² (12 AWG).
The wire connection method is screw-based, with an integrated wire guard to prevent under-insertion.
The dimensions are 92.2 mm in length, 20.1 mm in width, and 16 mm in depth.
It has a right-angle orientation, which facilitates space-saving mounting.
It is manufactured in Germany.
Yes, it is RoHS compliant, ensuring adherence to international environmental standards.
It includes a tool-less locking and gentle release lever, which reduces mechanical stress on solder joints during installation.
It is suitable for industrial, automation, power distribution, and control panel applications.
